Efficient mixing and cleanout
Three points of contact with the tub floor, made up of two bi-pulse legs and the leading edge of the screw help move material from the tub to the discharge conveyor for consistent distribution along a bunk line or tire.
Achieve a consistent, thorough mix with two overlapping screws and offset baffles on the tub wall. Instead of feedstuffs remaining in either the front or the back of the tub, the tub construction encourages the material to travel between the screws.
Convenient operation
Optimize rations and achieve defined targets when feeding in multiple pens with a 4-point scale. Plus, Bluetooth connectivity makes load weights accessible from a smart device.
Optional bidirectional discharge makes feeding convenient. Feed either on the right or left side of the alley when traveling between pens or multiple buildings.
Built to last
Equipped with 1/4-in (6.4-mm) tub material and 3/4-in (19-mm) floor thickness, this mixer is built to withstand load after load.
Help machine life and get ready for long-lasting performance with two extra heavy-duty planetaries powering the screw.
Designed for strength, longevity and versatility, the durable screws are made from abrasion-resistant, heat-treated AR200 steel.
Operators can be confident their mixer will withstand various types of feedstuffs with minimized rust and maximized durability by adding optional stainless steel liners.
| DIMENSIONS AND WEIGHTS | |
| Loading height - standard | 123 in |
| Machine weight - standard | 15580 lbs |
| Maximum net load | 21000 lbs |
| Total length | 277 in |
| Transport width - 50-in folding conveyor extension | 113 in |
| Working width - 50-in folding conveyor extension | 130 in |
| Tires (retread) | Standard 425/65R-22.5; Optional 255/70R-22.5 dual |
| TUB AND SCREWS | |
| Capacity | 750 cu ft |
| Number of screws | 2 |
| Number of knives per screw | 7 |
| Tub wall thickness | 1/4 in (6.4 mm) |
| Tub wall materialAR200 | |
| Floor thickness | 3/4 in (19.1 mm) |
| Screw flighting thickness | 5/8 in (15.9 mm) |
| Screw flighting material | AR200 |
| DISCHARGE SYSTEM | |
| Discharge style | Front conveyor |
| Discharge Direction | Left or right |
| Folding conveyor extension length | 25 in/40 in/50 in (64 cm/100 cm/130 cm) |
| Bi-directional conveyor length | 101 in/110 in/119 in (257 cm/280 cm/302 cm) OR 101 in (257 cm) hydraulic shift |
| Rear discharge door | Optional |
| TRACTOR REQUIREMENTS | |
| Minimum PTO horsepower | 150 hp (2-speed) (110 kW) |
| Recommended PTO horsepower | 180 hp |
| DRIVE SYSTEM | |
| Driveline | 1,000 rpm, CV |
| Two-speed gearbox | Optional |
| Torque Protection | Shear bolt |
| Screw rpm | 39 (1-speed); 39/26 (2-speed) |
| SCALE SYSTEM | |
| Scale display | Digi-Star EZ2810-BT |
| Number of weigh bars | 4 |
| Bluetooth connectivity | Standard |
| Remote Display | Optional |
