TM1410 Trailed Mower Features & Benefits

Maximized productivity

Maximize productivity with the Q3® cutter bar. Key features such as the Quick-Clip® blade retention system and Quick-Change™ shear ring are designed for productivity, functionality and to allow for quick and easy replacement in the field.

Convenient operation

Float over fields and contoured terrain with a nitrogen-charged accumulator suspension system that adjusts for varying field and crop conditions.

Two independent cutter bar units work with the suspension system to allow the mower to flex in uneven ground contour.

Built with the operator in mind

Want an even smoother ride? Optional 480/45 x 17 large float tires are available for the TM1210 trailed mowers.

Get more protection from unseen obstacles with the wide skid shoes and suspension system that help protect the cutter bars and the friction clutch, which protects the drive system.

Simple maintenance

Gain easy access to each individual cutter unit.

Replace blades in seconds using the exclusive Quick-Clip blade retention system.

TM1410 Trailed Mower Specs & Compare

DIMENSIONS AND WEIGHTS
Transport Height76 in
Transport width - standard9.1 ft
Transport width with flotation tires9.8 ft
Transport Length25.2 ft
Cutting Width20.8 ft
Working Height76 in
Working Width27.1 ft
Working Length19.8 ft
Total Weight6660 lbs
Tongue Weight1940 lbs
SuspensionHydraulic
Torque ProtectionDriveline: friction disc clutch
TiresStandard 31x13.5-15; Optional 480/45x17 flotation tire
TRACTOR REQUIREMENTS
Tongue/hitch2-point quick hitch with swivel gearbox, category II or III N
Drive PTO1000 rpm
PTO horsepower recommended105 hp
Hydraulic Type3 double-acting (2 double-acting with optional kit)
Hydraulic Pressure1850 psi
Hydraulic flow rate6 gpm
CUTTER BAR
Cutter bar typeQ3®
Cut height1 in - 3 in (2.5 cm - 7.6 cm)
Number of Discs14
Disc Diameter23 in
Disc Speed2690 rpm
Number of Blades28
Angle AdjustmentHydraulic pitch control
Quick Clip® blade retention systemStandard
Quick-Change™ shear ringStandard
Curtain material1400 g/m2 polyester woven material with flexible PVC covering
3-year limited cutter bar warrantyStandard
FEATURES
Optional swath formationOptional swathwheel
Skid ShoesStandard modular independent skid shoes; Optional topping wear skids
Highway LightsStandard
