Flexibility for different operations
Two options for discharge allow customers to tailor their wagon to fit their needs. A conveyor is typically the best option for rations of up to 20% roughage, whereas an auger works well for silage, grains and supplements.
Blend rations with various ingredients including up to 20% roughage to create a complete ration.
Low loading height
Have versatility with a low-profile loading height. This gives you flexibility between barns and buildings and allows you to load with most skid steers.
Convenient maintenance and operation
Low tractor horsepower requirements and a simple design make this machine a good fit for operators looking for a wagon that is simple to use and maintain.
Optimize feed placement into tires, bunks or wherever else you may be feeding with high discharge.
| DIMENSIONS AND WEIGHTS | |
| Machine weight | 3400 lbs |
| Transport Width | 110 in |
| Working Width | 120 in |
| Total height | 84 in |
| Loading height | 70 in |
| Tires | 295/75R-22.5 |
| BOX | |
| Capacity | 250 cu ft |
| Inside box length | 162 in |
| Inside box width - below flare | 60 in |
| Inside box width - above flare | 66 in |
| Floor material | Steel |
| DISCHARGE SYSTEM | |
| Discharge style | Conveyor or auger |
| Discharge Direction | Left |
| Conveyor Length | 94 in |
| Auger Length | 94 in |
| TRACTOR REQUIREMENTS | |
| Recommended PTO horsepower | 60 hp |
| Hydraulic Type | Optional, 1 double-acting |
| Hydraulic pressure | Optional, 1800 psi (124 bar) |
| Hydraulic flow | Optional, 10 gpm (38 L/min) |
| DRIVE SYSTEM | |
| Mechanical drive | Standard |
| PTO speed | 540 rpm |
| Hydraulic drive | Optional hydraulic orbit motor |
| SCALE SYSTEM | |
| Scale display | Digi-Star EZ2500V |
| Number of weigh bars | 3 |
| Jack stand weigh bar | Optional |
