Productivity and reliability acre after acre
A breakaway system helps protect the cutter bar by getting it out of the way in the event of a collision with an obstacle. After colliding with an obstacle, the cutter bar returns to the operating position without the operator having to leave the cab.
Hydraulic suspension on each side of the combination mower ensures excellent adaptation to the ground and a precise cut and clean forage in a variety of terrains and in all conditions.
Achieve efficiency and a premium cut with a robust cutter bar made with 4-mm (0.16-in) specially shaped pods that allow rapid forage flow, even when on slopes.
Efficiency during operation
Blades are simple and quick to replace to help minimize downtime for replacement – plus, reversible blades offer extended usability.
Navigate headlands efficiently with a sequential lifting system that uses hydraulic stabilization to lift the insides of the cutter bar first.
Durability for long-lasting performance
Each pod is made from abrasion-resistant Hardox® steel to provide you with long-lasting performance acre after acre.
A robust, yet simple frame is strong enough to support the mower when folded, yet gives plenty of accessibility for easy hook-up so you’re ready to tackle the field with ease.
Protect damage to the internal components of your cutter bar with shear protection.
Abrasion-resistant Hardox wear skids feature a large surface area to help protect the cutter bar and lengthen service life.
Options to fit your operation
Choose the best option for your specific needs with options for a rubber roller conditioner, steel flail conditioner or a mower without a conditioner.
An optional electric selector cuts the standard two remotes down to just one so operators can control the cutter units individually or in tandem.
| Dimensions and Weights | |
| Transport Height | 157.5 in |
| Transport width - standard | 10 ft |
| Transport Length | 8.4 ft |
| Cutting Width | 29.3 ft |
| Working Height | 60 in |
| Working Width | 32 ft |
| Working Length | 7.2 ft |
| Cutter bar lift height clearance | 22 in |
| Total Weight | 5160 lbs |
| Total weight - with rubber roller conditioner | 6810 lbs |
| Total weight - with tine conditioner | 6658 lbs |
| Suspension | Hydraulic |
| Torque Protection | Friction and over-running clutch |
| Tractor Requirements | |
| Tongue/hitch | Front 3-point, CAT II |
| Drive PTO | 1000 rpm |
| PTO horsepower recommended | 200 hp (150 kW) when used with front mower |
| PTO horsepower recommended - with rubber roller conditioner | 240 hp (180 kW) when used with front mower |
| PTO horsepower recommended - with flail conditioner | 230 hp (170 kW) when used with front mower |
| Hydraulic Type | 2 double-acting, 1 single-acting |
| Hydraulic Pressure | 2030 psi |
| Cutter bar | |
| Cutter bar type | Gear bed cutter bar |
| Cut height | 1.6 in - 2.8 in (4 cm - 7 cm) |
| Number of Discs | 16 |
| Disc Speed | 3000 rpm |
| Number of Blades | 32 |
| Angle Adjustment | Top-link on 3-point |
| Quick Clip® blade retention system | Quick blade change |
| Quick-Change™ shear ring | 4 brass pins shear protection |
| 3-year limited cutter bar warranty | Standard |
| Features | |
| Optional swath formation | Without conditioner: swath wheels; With conditioner: swathboards |
| Skid Shoes | Standard wear skids, optional topping skids |
| Highway Lights | Standard |
| Roller Conditioner | |
| Type | Intermeshing rubber rollers |
| Conditioner Drive | (3) V-belt |
| Conditioner Width | 105 in |
| Roller Diameter | 8.9 in |
| Roller Speed | 1000 rpm |
| Windrow width minimum | 44 in |
| Windrow width maximum | 91 in |
| Topping high cut kit | Optional topping skids |
| Flail conditioner | |
| Type | Steel V-tine |
| Conditioner Drive | Cogged belt |
| Conditioner Width | 105 in |
| Working Diameter | 19 in |
| Tine Speed Low | 750 rpm |
| Tine Speed High | 1000 rpm |
| Windrow width minimum | 75 in |
| Windrow width maximum | 106 in |
| Topping high cut kit | Optional topping skids |
