Features
- The patented 5-ply rubber conveyor belt design features offset rows of cupped cleats to minimize seed damage while providing a greater carrying capacity:
- The 8” conveyor features an unloading speed of up to 35 bushels per minute
- Hoppers are extra wide for unloading convenience and feature a lower hinged cleanout door for easily removing leftover seed and a protective grating over the intake for enhanced operator safety
- The hopper design is ideal for unloading bulk seed bags yet versatile enough to also work easily with wagons and bins
- The hitch features tool-free installation for moving the conveyor from one farm to the next and can be equipped with an optional transport chain for safer transport on roadways
- Equipped with your choice of orbital hydraulic or electric motor (single or three-phase)
- Hydraulic operating speed of 350 r.p.m. with 21' model and 230 r.p.m. with 30' and 35' models for the gentlest seed handling
- Convenient dual lever controls for easily controlling the speed of the hydraulic motor
- Models are available in 8" x 21', 8" x 30' and 8" x 35' sizes
Specs
| Model | 8' x 21' | 8' x 30' | 8' x 35' |
| Transport Height | 9'11" | 11'1" | 11'9" |
| Transport Length | 24'11" | 35' | 39'10" |
| Maximum Discharge Height | 13' | 21'9" | 24'3" |
| Minimum Discharge Height | 8'3" | 6'11" | 9'4" |
| Maximum Overall Height | 15'6" | 24'8" | 26'10" |
| Minimum Overall Height | 10'9" | 11'5" | 12' |
| Reach - Maximum Height | 3'4" | 6'6" | 10'3" |
| Reach - Minimum Height | 5'5" | 11'3" | 14' |
| Average Capacity @ 30° Angle | 1,500 bph | 2,040 bph | 2,040 bph |
| Approx. Weight (lbs.) | 1060 | 2,030 | 2,325 |
| Due to continuing improvements in the design and manufacture of Unverferth seed conveyors, all specifications contained herein are subject to change without notice. |
