Features
500 HOUR OIL CHANGE INTERVALS
Vanguard® Engines with Oil Guard System reduce maintenance time and costs by up to 60%.**
ADJUSTABLE OPERATOR PLATFORM
The adjustable operator platform system with suspension is adjustable for a large range of weights and operating conditions, optimizing operator comfort and increasing productivity.
SPEED CONTROL SETTING
The 3-position speed control setting is easy-locking and conveniently located for smooth operation. No tools are required to easily change the control setting for operation in a range of conditions.
CONTOURED THIGH PAD
Ergonomically designed thigh pad with contoured edges provides superior operator comfort, allowing the operator to easily lean into turns and sloping terrain for easier operation.
HEIGHT-OF-CUT ADJUSTMENT
Cut height is easily changed from the operator compartment for easy curb climbing and trailer loading. The hand-operated deck lift can change cut height in 1/4" increments from 1.75"-5".
COMMERCIAL TRANSAXLE
Commercial Hydro-Gear® ZT-3800® transaxles are fully serviceable and designed for high performance.
ICD™ CUTTING SYSTEM
The innovative iCD™ Cutting System allows for better airflow, discharge and superior cut quality.
HIGH FUEL CAPACITY
An 8-gallon tank is centrally located in the operator tower for consistent balance. The fuel filler neck is conveniently located on the side of the unit for easy fuel refill.
Specs
| Model Number | 5901860 |
| Engine Brand | Vanguard® 810 cc EFI |
| HP (gross) * | 28 |
| Displacement (cc) | 810 |
| Number of Cylinders | 2 |
| Fuel Tank Capacity (gal) | 8 |
| Starting Type | Electric |
| Cutting Width (in) | 61 |
| Deck Construction | iCD™ Cutting System |
| Height-of-Cut (in) | 1.75 - 5 |
| Spindles | Aluminum |
| Transmission | Hydro-Gear® ZT-3800® Oil Cooling System |
| Drive Axles | 1.125 |
| Drive Tires (in) | 23 x 10.5-12 |
| Caster Tires (in) |
13 x 5-6, flat-free
|
| Ground Speed-Fwd (mph) | 0-10 |
| Ground Speed-Rev (mph) | 0-5 |
| Overall Length (in) | 72 |
| Overall Width (in.) deflector down / deflector up (model) | 77/64 |
| Dry Weight (lbs) | 998 |
| Certified Rollover Protection System (ROPS) | N/A |
| Instrumentation | Engine and PTO hour meter, fuel level gauge |
| Controls/Safety Group | Operator presence in platform, Parking brake safety circuit for starting engine, Automatic PTO restart |
| Parking Brake/Safety Circuit | Internal Transaxle |
| *All power levels are stated gross horsepower at 3600 RPM per SAE J1940 as rated by Briggs & Stratton. |
