FEATURES

• Single 30" belt-over-bar conveyor
• All necessary mechanical, hydraulic and electrical connections to chassis
• Hopper mounted transport lighting and reflectors
• Manual adjustable chain tension
• Manual adjustable gate height
• Subframe and 4-point mounting for sprayer chassis

OPTIONS

Bolt-On, Interchangeable Spinners

Standard: MagnaSpread Spinners - offer true driving intervals, reducing swath overlap (driving interval of 60 feet with Lime, 80 feet with Fertilizer).

Optional: Javelin Spinners - offer the widest swath for urea in the industry
(driving interval of 120 feet with Urea).

Optional Section Control

Apply material in a full swath, to the left only, or solely to the right of the spreader, using split conveyor chains and independent spinner control.

Multi-Hopper Offerings

Multi-hopper spreaders can be used to vary the rate of N, P and K in one pass, with higher accuracy in fewer passes. Multi-hoppers can also be used to blend multiple fertilizers, micro-nutrients and/or cover crops.

• Hopper construction in carbon steel, 304 stainless steel or 409 painted stainless steel
• Wide array of hopper sizes for range of capacity and special clearance options

HYDRAULIC FEATURES & OPTIONS

• High quality JIC fittings & true hydraulic pipe
• GR Valve - increasing chain speed
• Hy-Torque manifold - increasing available spinner torque

STANDARD Javelin / Magnaspread convertible spinner system

Change between a 120' swath fertilizer system and 80' lime system in less than 30 minutes!

Optional Tee-Jet IC-38 ISOBUS Variable Rate Control with Scale Based Dynamic Metering

New Tee-Jet IC-38 controller option uses weigh scale readings to reconcile the controller settings with actual meter output.

CONTROLLER OPTIONS

Rate Control Ready for John Deere RC2000 ECU*
Includes: Spinner speed control, meter flow control, meter encoder, bin level sensors, harnessing, and connections to cab display (2630, 4600 or 4640 displays) *RC2000 ECU not included.

Tee-Jet IC-38 ISOBUS Controller with Weigh Scales for Dynamic Metering
Includes: Full rate control package with IC-38 ECU and harnessing, updated sub-frame and weight scale package, harnessing to cab.

CHASSIS COMPATIBILITY & HOPPER CAPACITY
- 4930: 200 cu-ft: F, L 300 cu-ft: F
- 4940: 200 cu-ft: F, L 300 cu-ft: F
- R4030: 200 cu-ft: F 300 cu-ft: N/C
- R4038: 200 cu-ft: F 300 cu-ft: N/C
- R4045: 200 cu-ft: F,L 300 cu-ft: F
F = Fertilizer Use / L = Lime Use / N/C = Not Compatible

CONVEYER TYPE
- SS200DS: Belt-Over-Bar
- SS300DS: Belt-Over-Bar

CONTROLLER OPTIONS
Rate Control Ready for John Deere® RC2000 ECU*
- Includes: Spinner speed control, meter flow control, meter encoder, bin level sensors, harnessing, and connections to cab display (2630, 4600 or 4640 displays) *RC2000 ECU not included.
Tee-Jet IC-38 ISOBUS Controller with Weigh Scales for Dynamic Metering
- Includes: Full rate control package with IC-38 ECU and harnessing, updated sub-frame and weight scale package, harnessing to cab .

HOPPER OPTIONS
- Stainless Steel Overslung Removable Inverted 'V'
- Shurco Cable-Lok Electric Tarp System with Remote Control

ACCESSORIES
- Spreader Pan Test Kit
- Fertilizer Grade Tester
- Fertilizer Crush Tester
