Features
- Three-Blade Design With 1” Blade Overlap Reduces the Possibility of Streaks and Skips in Your Yard.
- Available in 5’, 6’, and 7’ Widths to Provide the Best Match for Your Yard and Tractor.
- Top and Bottom Hitch Points "Float," Allowing the Mower to Ride With the Terrain.
Specs
| Model | FA-713 |
| Mowing Width | 83'' |
| Overall Width | 87'' |
| Blade Number | 3 |
| Cutting Height | 1 1/2'' - 4 1/2'' |
| Height Adjustment | Bushing |
| Hitch | CAT 1 |
| Blades | 6mm x 60mm |
| Blade Overlap | 1'' |
| PTO HP Required | 30 - 60 |
| Gearbox Ratio | 1:2.8 |
| Blade Tip Speed | 15,257 FPM |
| Cut Capacity (Max.) | Grass |
| Driveline Size | Cat 3 ASAE |
| Drive Belt Selection | 'B'' |
| No. of Drive Belts | 2 |
| Deck Thickness | 5mm (.197'') |
| Tire & Wheels | Solid |
| Anti-Scalp Roller | Standard |
| Discharge | Rear |
| Approx. Weight (lbs) | 816 lbs. |
