Patz 2800 Series Trailer Super Twin Screw
The Vertical Mixing Game-Changer
- Capacities: 1300 - 1600 ft³
- Designed Specifically for Today's Heaviest, High-Performance Dairy Rations
- Ideal for High-Capacity, High Concentrate, and Liquid Feed Supplemented Diets
- Feed with the Capacity of Triple Screw in the Precision and Efficiency of a Twin
Shopping Tools
2800 Series Trailer Super Twin Screw Features & Benefits
DRIVE PACKAGE
T3 Autoshift
VORTEX® SCREW
Vortex® Screw mixes quickly without compromising feed quality. Constructed of welded steel with 5/8″ cupped fliting. Multi-angle design option. Pre-drilled to accept knives.
VERTICAL MIXER KNIVES
KNIFE OPTIONS:
Patz vertical screw knife positions are laser cut, ensuring optimal knife placement for fiber processing and torque distribution. Select from 10”, 12”, and 21 ½” serrated knives available in tungsten/carbide coating or AR400 steel to optimize particle length.
Add Patz aggressive RAPTOR® knives for bale processing with patented forward-facing design to keep long hay in the mix.
XH (EXTRA HEAVY) UNITS
XH (Extra Heavy) units feature a welded steel tub with 3/8″ thick walls and a 3/4″ reinforced bottom.
SIZE KIT
Metal extension to increase basic unit mixing capacity. Add overall height 9-1/4″ or 16″.
DISCHARGE CONVEYOR
Discharge conveyor option for front door or side discharge openings. Choice of fixed or sliding flat conveyors with right-hand, left-hand, or reversible discharge.
CAMERA PACKAGE
View rear of mixer from tractor cab while backing up or discharging feed from optional rear commodity door. Includes 7″ LCD monitor and weatherproof, shock-resistant infrared camera for night vision.
TUB MOUNTED MAGNET (OPTIONAL)
Patz patented tub-mount magnet is strong enough to pull tramp metal from the ration while mixing. Encased in stainless steel and tub wall mounted on an easy access hinged assembly for safe, routine removal of errand, ferrous metal.
2800 Series Trailer Super Twin Screw Specs & Compare
| 2800 Series Trailer Super Twin | 1300XH | 1475 ft³ Size Kit | 1600 ft³ Size Kit |
| Mixer Capacity | 1,300 ft³ (36.8 m³) | 1,300 ft³ (36.8 m³) | 1,300 ft³ (36.8 m³) |
| Capacity with Extensions | 1,300 ft³ (36.8 m³) | 1,475 ft³ (41.8 m³) | 1,600 ft³ (45.3 m³) |
| Max. Load Capacity | 45,500 lbs. (20,638 kg) | 51,625 lbs. (23,417 kg) | 56,000 lbs. (25,401 kg) |
| Height | Singles: 137.38 in. (3.49 m) Duals: 138.53 in. (3.52 m) | Singles: 146.675 in. (3.72 m) Duals: 147.78 in. (3.75 m) | Singles: 153.38 in. (3.9 m) Duals: 154.53 in. (3.92 m) |
| Width | 127.75 in. (3.24 m) | 127.75 in. (3.24 m) | 127.75 in. (3.24 m) |
| Length | 358 in. (9.1 m) | 358 in. (9.1 m) | 358 in. (9.1 m) |
| Tractor Horsepower Required | 250 HP | 250 HP | 250 HP |
| PTO Operating Speed | 700 - 1000 RPM | 700 - 1000 RPM | 700 - 1000 RPM |
