New standard in cow comfort and herd health

  • The most optimized and efficient alley scraper systems
  • Sentinel Control Panel learning system constantly adjusts to weather, bedding, and manure changes while recalculating the amount of torque needed to pull to the drop point – UL/cUL certified.
  • Energy-efficient planetary gearbox ranging from a ¾ – 3 HP motor!
  • Layout flexibility with narrow, space-saving drive unit
  • On-floor or recessed chain can be easily installed in new or existing barns
  • Get a Quote Value Your Trade
  • Send to a Friend
  • Payment Calculator

    • Get information on the IntelliChain® Alley Scrapers

    Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.

    Send your friend information on the IntelliChain® Alley Scrapers

    Fields with asterisks* are required. Your friend will receive an email that contains a reference to this page. Please send this email only to people you know who would be interested in this information.

    Requesting Trade In on IntelliChain® Alley Scrapers

    Contact Information
    Equipment Interested In
    Trade Information

    Request A Demo

    Fields with asterisks* are required.

    Loan Calculator

    Use the Loan Calculator to help you determine the financing and payment options that are best for you.

    Amount Financed ($)
    Interest Rate (%)
    Loan Term in Months
    Monthly Payment Calculated

    **The accuracy of this calculator and its applicability to your circumstances is not guaranteed. You should obtain personal advice from qualified professionals. This information is provided for illustrative purposes only and does not constitute an application. This notice does not guarantee loan approval, nor is it an offer or commitment to make a loan to you on the above terms.

Shopping Tools
Contact Salesman
Request Demo
Apply for Financing

IntelliChain® Alley Scrapers Features & Benefits

Standard Features & Options


SENTINEL CONTROL PANEL
Advanced learning system continuously adjusts to weather, bedding, and manure changes by recalculating the amount of energy required to clean on every cycle.

Patz innovative patented Auto-Tensioning option
Superior sensitivity – programmable BUMP feature.
Advanced “Patz Remote Notification” emails and/or text messages operator(s) with scraper status and service updates. Transmits updates following corrective service.

POCKET SPROCKET

Pocket sprocket cradles the chain, effectively driving it in forward or reverse. The IntelliChain II is connected to the reducer with a tapered bushing.  The IntelliChain HD and MAX are splined hubs and the sprocket bolts to it.  They are easy to replace and available in five different colored stages for easy identification.

DRIVE UNIT CONFIGURATIONS
Drive unit foot wheels can be placed in straight, corner, parallel, or offset mounting formations for layout flexibility and space savings. Steel housing encloses through-hardened drive unit foot wheels for safety and protection. Foot wheels feature sleeve bearings for longer life.

SCRAPERS
FOLDING V SCRAPER
Low-profile scraper wings and folding design allow easy passage for animals and equipment.  Cleans alleys 64″ – 174″ wide.

FOLDING ANGLED TIP-UP SCRAPER
Wings pivot to follow wall tightly for better cleaning; blades tip up and the wings pivot inward on reverse movement. Suitable for alleys with widths from 84″ – 192″ (2.1-4.9 m).

VERSA FOLDING V-SCRAPER
This versatile, low-profile scraper is available in: 6, 8, 10, 12, and 14 foot sizes.  Cleans 64″ – 174″ wide alleys with widths.  Choose from three economical, replaceable blade edges: AR400 steel, rubber, or urethane.

CORNER WHEEL OPTIONS
Corner wheel options are available to accommodate various barn designs and bedding applications.

*Shown:  Low-profile corner wheel

PATZ® CHAIN
Made of 1/2″ (13mm) hardened steel, the Patz Chain withstands the stress and friction of contact between links and concrete alleys.  Chain can be ordered in a variety of lengths for splice-free installation.

IntelliChain® Alley Scrapers Specs & Compare

IntelliChainIIII HDMax
Motor3/4 HP Electric1 HP Electric2 or 3 HP Electric
Total Circuit Length (TCL), Maximum1,000′ (305m)1,800′ (549m)2,500′ - 3,600′ (762 - 1,097m)
