The Perfect Pairing: Orthman and John Deere
The Orthman DR-Series planters are available with the innovative lineup of John Deere planter technology. Depending on model and configuration, electric drive DR-Planters are available with either the ExactEmerge™ or MaxEmerge™ 5e planter row units. Hydraulic drive Twin Row DR-Planters are available with the MaxEmerge™ 5 planter row units. Depending on the size, row spacing and configuration, DR-Planters are available with a 100-, 70- or 55-bushel Central Commodity System (CCS™).  Individual row unit seed hoppers are also available with sizes of 3.0-, 2.0- and 1.6-bushels.

Toolbar Design
12-, 16- and 18-row 30" models are available with a vertical or stack-folding design and can be configured as a fully mounted 3-point toolbar or as a 3-point mounted toolbar with lift-assist wheels. The DR-12, DR-16 and DR-18 30" planters are available with 55-, 70- or 100-bushel CCS tanks from John Deere, and the DR-18 30" model can also be configured with 1.6- or 3.0-bushel row unit seed hoppers.

24-Row 30” Planter
The 24"-row 30" Orthman DR-Series planter is available with a stack-folding toolbar and SEMI-mount pull-type frame for a short-coupled design that maximizes maneuverability in and around the field. The DR-24 is available with 6 center section 22.5" lift wheels for better flotation and enhanced weight distribution. You can also configure this model with 480/80 R50 tractor tires and a 1,000-gallon liquid fertilizer tank that is integrally mounted with the toolbar frame. The DR-24 30" is available with a 100-bushel CCS and 1.6- or 3.0-bushel row unit seed hoppers from John Deere.

  • Get a Quote Value Your Trade
  • Send to a Friend
  • Payment Calculator

    • Get information on the 30" DR-Planters

    Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.

    Send your friend information on the 30" DR-Planters

    Fields with asterisks* are required. Your friend will receive an email that contains a reference to this page. Please send this email only to people you know who would be interested in this information.

    Requesting Trade In on 30" DR-Planters

    Contact Information
    Equipment Interested In
    Trade Information

    Request A Demo

    Fields with asterisks* are required.

    Loan Calculator

    Use the Loan Calculator to help you determine the financing and payment options that are best for you.

    Amount Financed ($)
    Interest Rate (%)
    Loan Term in Months
    Monthly Payment Calculated

    **The accuracy of this calculator and its applicability to your circumstances is not guaranteed. You should obtain personal advice from qualified professionals. This information is provided for illustrative purposes only and does not constitute an application. This notice does not guarantee loan approval, nor is it an offer or commitment to make a loan to you on the above terms.

Shopping Tools
Contact Salesman
Request Demo
Apply for Financing

30" DR-Planters Features & Benefits

A 30" Row Spacing Planter with the Widest Range of Configurations
The 30" lineup of Orthman DR-Series planters feature a wide range of sizes and seed hoppers to fit your operation's exact needs. With seed hopper capacities up to 100 bushels, you'll be in the field longer, increasing efficiency and getting your crop in the field faster. DR-Planters with 30" row spacings are available in 12-, 16-, 18- or 24-row sizes.

30" DR-Planters Specs & Compare

Size12-Row
30" DR-Planter
Spacing30"30"30"
Fold / MountingVertical / 3-PointStack / 3-Point w/LAWStack / 3-Point w/LAW
ToolbarDouble 5x7 & 7x7Single 7x7Single 7x7
HitchCAT4CAT 3 & 4CAT 3 & 4
DriveElectricElec. & Hyd.Hydraulic
Seed Hopper55 bu. CCS70/100 bu. CCS55 bu. CCS
Rows on Center666
Rows on Wing333
Trans. Width16' 11"17' 11"17' 11"
Trans. Height13' 6"12' 8"12' 11"
Trans. Length7' 3"12' 10"8'3"
Approx. Empty Weight9,670 lbs11,880 lbs.7,685 lbs.
Wing DownforceWing DownforceWing DownforceWing Downforce
Wing Flex+/- 8 deg+/- 8 deg+/- 8 deg



Size16-Row
30" DR-Planter
Spacing30"30"30"30"
Fold / MountingStack / 3-Point w/LAWStack / 3-PointVertical / 3-PointVertical / 3-Point
ToolbarSingle 7x7Single 7x7Double 5x7 & 7x7Double 5x7 & 7x7
HitchCAT4CAT3CAT4CAT4
DriveElectricHydraulicElectricElectric
Seed Hopper100bu55 bu. CCS70/100 bu. CCS55 bu. CCS
Rows on Center8888
Rows on Wing4444
Trans. Width23' 10"23' 10"22' 5"22' 5"
Trans. Height12' 8"14'14' 5"14' 5"
Trans. Length12' 10"8'3"15' 2"15' 2"
Approx. Empty Weight12,880 lbs.10,500 lbs.12,560 lbs.12,545 lbs.
Wing DownforceWing DownforceWing DownforceWing DownforceWing Downforce
Wing Flex+/- 8 deg+/- 8 deg+/- 8 deg+/- 8 deg



Size18-Row
30" DR-Planter
Spacing30"30"30"
Fold / MountingStack / 3-Point w/LAWVertical / 3-PointVertica l/ 3-Point
ToolbarDouble 5x7 & 7x7Double 5x7 & 7x7Double 5x7 & 7x7
HitchCAT4CAT4CAT4
DriveHydraulicElectricElectric
Seed Hopper1.6/3.0 bu. & 100 bu. CCS55 bu. CCS70bu
Rows on Center888
Rows on Wing555
Trans. Width20' 8"23'23'
Trans. Height14' 6"15' 9"15' 9"
Trans. Length13' 7"7' 2"7' 2"
Approx. Empty Weight19,900 lbs.13,025 lbs13,110 lbs
Wing DownforceGull Wing UpWing DownforceWing Downforce
Wing Flex+/- 8 deg+/- 8 deg+/- 8 deg



Size24-Row
30" DR-Planter
Spacing30"30"30"
Fold / MountingStack / SEMI 2-Point Qty 6-22.5" TiresStack / SEMI 2-Point w/480/80 R50 Tires*Stack / SEMI 2-Point Qty 6-22.5" Tires
ToolbarDouble 5x7 & 7x7Double 5x7 & 7x7Double 5x7 & 7x7
HitchCAT3CAT3CAT4
DriveHydraulicHydraulicElectric
Seed Hopper1.6/3.0 bu. & 100 bu. CCS100bu100bu
Rows on Center888
Rows on Wing888
Trans. Width23' 0"23' 2"23' 4"
Trans. Height14' 2"14' 11"14' 9"
Trans. Length16' 2"27' 8"16' 6"
Approx. Empty Weight23,480 lbs.28,480 lbs.26,125 lbs.
Wing DownforceGull Wing UpGull Wing UpWing Downforce
Wing Flex+/- 8 deg+/- 8 deg+/- 16 deg

Due to continuing improvements of Unverferth products, all specifications contained herein are subject to change without notice. LAW = Lift-Assist Wheels.
*Model features a 1,000 gallon liquid fertilizer tank integrally mounted with the toolbar frame (does not include any plumbing or wet gear).
