Set it and forget it. That’s right. With the ultra user-friendly WP1, manage your soil, water and residue all in a single tillage pass.
  • Get a Quote Value Your Trade
  • Send to a Friend
  • Payment Calculator

    • Get information on the 2411-6-24

    Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.

    Send your friend information on the 2411-6-24

    Fields with asterisks* are required. Your friend will receive an email that contains a reference to this page. Please send this email only to people you know who would be interested in this information.

    Requesting Trade In on 2411-6-24

    Contact Information
    Equipment Interested In
    Trade Information

    Request A Demo

    Fields with asterisks* are required.

    Loan Calculator

    Use the Loan Calculator to help you determine the financing and payment options that are best for you.

    Amount Financed ($)
    Interest Rate (%)
    Loan Term in Months
    Monthly Payment Calculated

    **The accuracy of this calculator and its applicability to your circumstances is not guaranteed. You should obtain personal advice from qualified professionals. This information is provided for illustrative purposes only and does not constitute an application. This notice does not guarantee loan approval, nor is it an offer or commitment to make a loan to you on the above terms.

Shopping Tools
Contact Salesman
Request Demo
Apply for Financing

2411-6-24 Features & Benefits

  • Laser Cut, Robotically Welded Frame
  • 5 1/2” Lift Axles with Maintenance-Free Lift System
  • Walking Tandems on All Sizes
  • Slip-In Spindles
  • 340/60R x 18, 400/60R x 18 Tires (Model Dependent)
  • Self-Leveling Hitch with Manual Adjustment
  • Cast Single Lip Hitch Cat. IV
  • Single-Point Depth Control
  • 24” or 26” Disc Blades Spaced at 10 1/2”
  • 15 Degree Gang Angle Front and Rear
  • Heavy-Duty Scrapers
  • 1 3/4” Gang Bolt
  • Trunnion Mount Bearings
  • C-Cushion Bearing Mounts
  • Overlapping/Staggered Offset Tandem Disc Gangs
  • Staggered Shank Arrangement
  • Auto-Reset Shanks with 3,600 lb. Point Load
  • Variety of Points Available
  • Adjustment/Maintenance Wrenches
  • Blue Powder Coat Paint
  • Safety Warning Lights

2411-6-24 Specs & Compare

Product Attributes 2411-6-24
Approximate Weight 17,175 lbs. (7,790 kg)
Working Width 12 ft. 0 in. (3.7 m)
Transport Width 15 ft. 4 in. (4.7 m)
Transport Height
(Excluding Rear Attachment)		 N/A
Number of Disc Blades - Front 16
Number of Disc Blades - Rear 18
Blade Spacing - Front 10.5 in. (267 mm)
Blade Spacing - Rear 10.5 in. (267 mm)
Blade Sizes 24 in. x 0.25 in. (610 x 6.4 mm) Rollable
24 in. x 0.25 in. (610 x 6.4 mm)
26 in. x 0.25 in. (660 x 6.4 mm)
26 in. x 0.3125 in. (660 x 7.9 mm)
Blade Concavity 3 in. (76.2 mm)
Blade Scrapers 4.5 in. (114 mm) Adjustable
Blade Scraper Mount Heavy-Duty 0.625 in. (15.9 mm) Spring Steel Arm
Gang Spools - Front 5.5 in. (140 mm) Diameter
Gang Spools - Rear 5.5 in. (140 mm) Diameter
Gang Angle - Front 15 Degrees Non-Adjustable
Gang Angle - Rear 15 Degrees Non-Adjustable
Gang Shaft 1.75 in. (44.5 mm) Round
Number of Gang Bearings - Front 6
Number of Gang Bearings - Rear 6
Gang Bearing Type C-Cushion Trunnion Mount, Greaseable Triple Lip Seals
Gang Height Adjustability 12 in. (304.8 mm)
Number of Shanks 6
Shank Spacing 24 in. (610 mm)
Shank Depth (Maximum) 14 in. (356 mm)
Point Load 3,600 lbs. (1633 kg)
Trip Height 14 in. (356 mm)
Shank Size 1.25 in. x 4 in. (31.8 x 102 mm)
Shank Type Auto-Reset Parabolic
Standard Point 2.5 in. (63.5 mm) CADI Point
Standard Wear Guard V-Shaped CADI Wear Guard
Transport Lift Axles 5.5 in. (140 mm) with UHMW Maintenance Free Pivots
Transport Axle Type Walking Tandems with Greaseable Pivots
Tire Size - Main Frame (4) 340/60R x 18
Wheel Hubs - Main Frame 8-Bolt
Spindles - Main Frame 2.25 in. (57.2 mm) Slip-In Spindles
Tire Size - Wing Frame N/A
Wheel Hubs - Wing Frame N/A
Spindles - Wing Frame N/A
Hitch Type Self-Leveling with Manual Adjustment
Hitch Category Cast Single Lip Cat. IV with Ball
Machine Depth Control Single Point, Front Mounted
Safety Warnings Lights and SMV Emblem Standard
Safety Chain Kit Standard
Adjustment Wrenches Standard
Powder Coat Paint, Blue Sapphire Standard
Cat. III Single Lip Hitch Clevis Optional
Cat. V Single Lip Hitch Clevis Optional
Shark Fin CADI Point Optional
7 in. Wing Point with Chrome Cap Optional
7 in. Wing Point with Cast Cap Optional
10 in. Wing Point with Chrome Cap Optional
10 in. Wing Point with Cast Cap Optional
Spare Tire & Wheel Assembly Optional
Rigid Shear Bolt Shank Optional
Horsepower Requirements 50 HP and up (27 kW) per Shank

Specifications subject to change with or without notice.
