Features
| Features | Benefits |
| Attaches to power equipment easily | Uses universal quick hitch design for quick and easy attachment. |
| Universal quick hitch option or old style Kubota B Series hitch option | The quick attach plate mounted grapple can be attached to a wide variety of machines |
| No mount option | This option has no mount on the back of the grapple and allows the customer to install a mount of their preference. |
| Designed to protect hydraulic hoses | Hydraulic hoses routed to prevent pinching. |
| Greasable hardened bushings at upper grapple pivot locations | Bushings can be replaced if needed. |
| 1" Pivot pins | Large diameter pins for extra strength. |
| Dual hydraulic cylinders | Allows upper claw to grip the material better |
| AR400 teeth material | More than double the strength of mild steel. |
| Hardened bushing at cylinder mount points | Bushings can be replaced if needed. |
| High volume cage design | Can handle large volume of material. |
| Rear facing lower teeth | Can be used for pulling roots or back dragging. |
Specs
| Model | SGC1072 |
| Weight Universal quick hitch Kubota B Series hitch |
447 lbs 436 lbs |
| Width | 75" |
| Closed height | 34 1/8" |
| Jaw opening | 39 1/2" |
| Number of teeth | 12 Bottom & 11 Top |
| Teeth spacing | 6 3/8" Bottom & 6 1/4" top |
| Tooth thickness for upper and lower jaws |
All outside teeth are 1/2" thick All teeth between outside teeth are 3/8" thick |
| Working length of teeth | 11 1/2" |
| Hydraulic cylinder | 2" x 6" x 1 1/8" Rod |
| Maximum pressure rating | 3500 psi |
