Features
| Features | Benefits |
| 84" & 96" Working Widths | Covers tire tracks and allows user to cover large areas in less time. |
| 30-80 Tractor HP Range | Fits many tractors with a Cat. l or Cat. ll 3-point hitch. |
| Quick Hitch Compatible | Fits Land Pride Quick Hitch for a quick and easy one person hook-up. |
| Retractable Parking Stand | Keeps frame off the ground and makes hook-up easier. |
| 2 1/2" Pivot Shaft | Heavy-duty shaft. Heaviest in its class. |
| 16 1/2" Rake Height | Can move a great deal of material. |
| Rake Teeth Support Channel | Design with channel support. This design supports the rake teeth better than competitor models. Prevents teeth entanglement and keeps attachment hardware from working loose. |
| 5/16" x 1" High-Carbon Spring Steel Teeth |
Sized to eliminate premature bending and tooth breakage. Constructed of materials that have “memory” to spring back to shape. |
| Individual Replaceable Teeth | Makes replacing a damaged tooth quick and easy without removing all of the teeth. |
| Rake Angle 5 Positions | Versatility in operation. Vary how much material to move. |
| Rake Offset 7 Positions | Versatility in operation. Allows the unit to work closer to objects on the side the rake is of set towards. |
| Dual Gauge Wheels (Accessory) | Gives operator better depth control. Wide & narrow wheels available. |
| Flip-Down Grader Blade with End Plates (Accessory) |
Enables the rake to perform light blading duties for moving and leveling dirt as well as other materials. Grader blade can be flipped up when not in use. |
| Rear Blade Attachment (Accessory) | The rake assembly can be removed from the main frame and a Rear Blade attached to give the Land Pride Rake versatility. |
| Hydraulic Angling (Accessory) | Allows operator to change rake angle from the tractor seat. |
Specs
| Model | LR3796 |
| Rake Width | 96" |
| Approximate Weight (lbs.) | 514 |
| Number of Teeth | 48 |
| Horsepower Rating | 30-80 |
| Hitch Category | Cat. l & ll Combination (Quick Hitch Compatible) |
| Pivot Shaft Diameter | 2 1/2" |
| Rake Height | 16 1/2" |
| Parking Stand | Standard |
| Individual Replaceable Teeth | Standard |
| Teeth Size | 5/16" x 1" Wide |
| Teeth Spacing | 2" Centers |
| Teeth Material | High-Carbon, Spring Steel |
| Rake Angle Standard (Manually) Hydraulically |
5 Positions, Maximum 30° Right or Left in 15° Increments Any Degree up to 45° |
| Rake Offset Manually | 7 Positions, Maximum 45° Right or Left in 15° Increments |
| Dual Gauge Wheels* (Accessory) | Dual Narrow Width Wheels 13" x 4" x 6" or Dual Wide Width Wheels 13" x 6.5" x 6" |
| Flip-Down Grader Blade (Accessory) | Flip-Down, Self-Supporting Grader Blade with Blade-up Locking Handles and Locking Pins |
| Rear Blade Attachment (Accessory) | Available in 72", 84" & 96" Working Widths |
