Features
| FEATURES | BENEFITS |
| Cat. 1 and Cat.1 Quick Hitch compatible. Has lower hitch clevis type mountings. |
Makes for faster and easier hookup to the tractor. |
| 20-50 hp requirements with 48" working width 25-50 hp requirements with 60" & 72" working widths. |
Makes it compatible with many popular smaller sized and properly ballasted compact utility tractors in use today. |
| Dual adjustable height grading blades and optional 4-position scarifier shanks. |
Allows the scraper to be adjusted to desired amount of cultivation, leveling, and grading action. |
| Reversible heat treated high carbon steel grading blades. |
For excellent wear resistance and long service life. |
| Hardened tips on optional scarifier shanks. | Assures long service life. |
| Replaceable and full length heavy gauge skid shoes. |
Makes for easier operation and long unit life. |
| Reversible skid shoes | Extends the life of the skid shoes. |
| Heavy duty frame construction. | Assures long lasting reliability and performance. |
| Available in Land Pride Beige or Orange Paint. |
To meet customers preference. |
Specs
| Model Numbers | GS1548 |
| Working width | 48" (1.22 m) |
| Overall width | 54 1/4" (1.38 m) |
| Number of scarifier shanks | 4 |
| Tractor horsepower requirement | 20-50 hp (14.9-37.3 kw) |
| Unit weight with shanks | 437 lbs (198.2 kg) |
| Overall length | 50" (1.27 m) |
| Overall height | 32" (81.3 cm) |
| Side panel height | 14" (35.6 cm) |
| Side panel length | 44" (1.12 m) |
| Side panel thickness | 3/16" (5 mm) Thick with 2 3/4" formed edges. |
| Front main beam & scarifier Support. | 4"x 4" x 5/16" (10.2 cm x 10.2 cm x 0.8 cm) Reinforced heavy wall tubing. |
| Rear beam construction | 2"x 2"x 3/16" (5.1 cm x 5.1 cm x 0.5 cm) Heavy wall tubing. |
| Skid shoe dimensions | 3/8" (10 mm) Thick x 2 3/4" (7.0 cm) wide x 44" (1.12 m) long. |
| Scarifier shank construction - Optional | Heat treated 4-position shank with dimpled-on hardened tips. |
| Cutting edges | Two 1/2" x 6" (1.3 cm x 15.2 cm) high carbon heat treated blades that are reversible and replaceable. |
| Cutting edge placement | Two parallel grading blades positioned at a 5 degree grading angle with 17 1/2" (44.5 cm) fore and aft spacing in between leading edges. |
| Cutting edge adjustment | Infinite vertical adjustment from level grade to 1 1/2" (3.8 cm) below grade. |
| Shank adjustments | 3 1/2" and 1 1/2" (8.9 cm and 3.8 cm) below grade level. 1/2" and 2 1/2" (1.3 cm and 6.4 cm) above grade level. |
| Lower draft link attachment | Clevis type |
| Hitch type | Category 1 and Category 1 Quick Hitch |
| Color selections | Land Pride Beige or Orange |
