Features
OPTIONAL REAR ROLLER BASKET
The optional rear roller basket breaks down clods to create a leveling action, a leading industry option.
OFFSET DESIGN
The offset design maximizes the clearance between the disc blades to help prevent plugging and this design eliminates the need for a middle breaker.
SINGLE POINT DEPTH CONTROL
Change the depth of the entire machine from one central location quickly and easily.
OFFSET C-SHANKS
Offset C-shanks cushion the gangs and protect the unit. The offset design also maximizes the clearance between the disc blades to help prevent plugging.
SPRING LOADED SCRAPERS
Standard scrapers are spring loaded; quickly make them rigid by tightening a bolt.
Specs
| Model | DH7115 |
| Horsepower | 105-135 HP |
| Hitch | Pull-type |
| Working Width (m) | 15' (4.6) |
| Transport Width (m) | 16' (4.88) |
| Weight - lb (kg) | 7,100 (3221) |
| Disc Blade Size | Smooth 22" x .197" Smooth 22" x .256" Smooth 24" x .197" Smooth 24" x .256" |
| No. of Disc Blades 7.5" Row Spacing 9" Row Spacing |
54 46 |
| Bearing Hanger | Spring C-Shank Bearing Hangers |
| Front Gang Angling | Fixed 20° Angle |
| Rear Gang Angling | Fixed 18° Angle |
| Gang Tubes | 4" x 6" |
| Gang Axle | 1-3/4" |
| Weight per Disc - lb (kg) 7-1/2" Spacing | 131 |
| Weight per Disc (kg) 9" Spacing | 154 |
| Transport Tires | Radial Tires, Dual on 15' Models |
| Finishing Reel | Optional |
| Disc Scrapers | Standard |
| Transport Lights | Standard |
