EasyCut B 870 CV · B 870 CR
The mower combinations with conditioners

• 8.70 m work width
• EasyCut B 870 CV with tine conditioner
• EasyCut B 870 CR with roller conditioner (rubber rollers or M-Rolls)
• A balancing arm ensures the ground pressure is uniform on either side
• A standard break-back system gives effective protection

EasyCut B 870 CV and CR utilize the tractor to the full and save time and costs. The versatile model is the EasyCut B 870. Featuring conditioners and extra wide merger belts,
this machine enables you to cut, condition and spread or swath the material in one single pass.

Convenient for operators
Holders on the machine store the oil hoses when the machine is removed from the tractor. The hose couplers have numbered handles for easier attachment and removal.

A KRONE exclusive!
The patented compensating rocker on the adjustable spring suspension system distributes the ground pressure evenly to both mowers. This feature guarantees cleanest cuts and forage, light pulling and protection of the valuable sward.

Simple driveline
The driveline is simple and efficient. A main gearbox on the headstock splits the power and sends it to the side mowers.

Double-acting rams
Double-acting rams provide dependable control of each unit as it lifts and lowers on slopes whereas single-acting rams lift them into headland position.

Limiting the pivot range
Hydraulic rams limit the transverse travel of the mowers that suspend in their center of gravity, giving plenty of ground clearance during the headland turn or travel on public roads.

All specifications, weights and dimensions do not necessarily comply with standard specifications and are therefore not binding. Specifications are subject to change without notice.
