Features
H-Bar® Steering
Patented steering is the easiest-to-use walk-behind system in the field, reducing operator fatigue.
Deck Lift
Easy-to-operate deck lift makes deck height adjustment a breeze.
Dual Hydro System
Heavy-duty traction and performance.
Service Friendly Design
Designed to make maintenance and service simple and easy.
Welded Steel Deck
Durable 10 ga. plus 11ga. reinforced steel with 11 ga. formed channel rolled edge. (36" deck model is 7ga. with 7ga. reinforced steel)
Specs
| Key Specs | TrimStar 48" |
| ENGINE MANUFACTURER | Kawasaki FS600 |
| ENGINE HORSEPOWER | 18.5 |
| TRANSMISSION | Hydro-Gear ZT-2800® |
| FUEL CAPACITY | 3.4 gal. |
| GROUND SPEED (FWD) | Up to 6.3 mph |
| CUTTING WIDTH | 48" |
| CUTTING HEIGHT | 1.5" to 4.5" |
| FRONT TIRE | 11 x 4-5 semi-pneumatic |
| DRIVE TIRE | 20 x 8-10 |
| Engine | |
| ENGINE MANUFACTURER | Kawasaki FS600 |
| ENGINE HORSEPOWER | 18.5 |
| DISPLACEMENT | 603cc |
| COOLING | Air Cooled |
| AIR CLEANER | Oval canister, dual element |
| Drive System | |
| TYPE | Dual Hydrostatic |
| TRANSMISSION | Hydro-Gear ZT-2800® |
| HYDRAULIC LINES | |
| RESERVOIR CAPACITY | 2 qts per side |
| HYDRAULIC COOLING | Pump mounted fan |
| FUEL CAPACITY | 3.4 gal. |
| GROUND SPEED (FWD) | Up to 6.3 mph |
| PARKING BRAKE | Internal transmission mechanical brake |
| Deck | |
| CUTTING WIDTH | 48" |
| CUTTING HEIGHT | 1.5" to 4.5" |
| DECK DEPTH | 5" |
| DECK LIFT | Hand Operated |
| NUMBER OF BLADES | 3 |
| BLADE LENGTH | 16.50" |
| BLADE TIP SPEED | 18,500 |
| SPINDLES | Aluminum with steel shaft and sealed ball bearings |
| DECK ENGAGEMENT | Electric PTO Clutch |
| DECK MATERIAL | 10ga + 11ga reinforced steel |
| SPINDLE MOUNTS | Reinforced 11 ga. |
| IMPACT TRIM AREA | 11ga formed channel rolled edge |
| ANTI-SCALP WHEELS | |
| Construction | |
| FRAME | 1.5" x 2" steel tubing |
| FRONT CASTER WHEEL | Tapered wheel bearings and debris cap |
| FRONT CASTER FORK | Fabricated 3/8" steel |
| Dimensions | |
| FRONT TIRE (INCHES) | 11 x 4-5 semi-pneumatic |
| DRIVE TIRE (INCHES) | 20 x 8-10 |
| WING TIRE (INCHES) | |
| WEIGHT (LBS) | 635 |
| HEIGHT (INCHES) | 42.5 |
| LENGTH (INCHES) | 75 |
| WIDTH W/ CHUTE UP (INCHES) | 49 |
| TIRE-TO-TIRE WIDTH (INCHES) | 44 |
| PRODUCTIVITY (ACRES PER HOUR) | 2.44 |
| Dimensions with Catcher | |
| CATCHER STYLE | Side Catcher |
| POWERED / NON-POWERED | Non-powered |
| CATCHER CAPACITY | 3.5 bushel |
| MOWER LENGTH W/ CATCHER | 74.55" |
| MOWER WIDTH W/ CATCHER | 68.7" |
Accessories and Attachments
Steel Side Bagger
Easy-on, easy-off bagger has a 3.5 bushel capacity.
Fits:
FasTrak SDX
FasTrak
X-ONE
Raptor XDX
TrimStar
Mesh Side Bagger
Easy-on, easy-off bagger has a 3-bushel capacity.
Fits:
X-ONE
TrimStar
Super S
Raptor XDX
FasTrak
FasTrak SDX
Surfer Pro
Mulch Kit
Recycle clippings back into the soil and reclaim nutrients for your lawn.
Fits:
X-ONE
Super Z
HyperDrive
Diesel Z
TrimStar
Stripe Kit
Helps provide a professional manicured finish to your lawn.
Fits:
Super Z
HyperDrive
Diesel Z
TrimStar
High Vacuum Deck Kit
Improves vacuum and cut quality while reducing blowout in thin/dry grass conditions.
Fits:
TrimStar
