Attachment Capable
Multi-purpose machine with detachable shaft and a wide variety of click-on tools and attachments (sold separately)
Attachment Capable
Easily breaks down for safer transport and compact storage
Metal skid plate
Durable metal skid plate protects the engine and fuel tank.
Auto return stop switch
Stop switch automatically resets to the ON position for trouble-free starting.
Stand alone starter
The stand alone starter makes it easy to change starter cord if needed.
High Line Capacity
Tap 'n' Go trimmer head is easy to use and refill
See-through fuel tank
See-through fuel tank for easier refueling.
Quick Start with Air Purge
Air purge removes air from carburetor and fuel system for easy starting
Comfort handle
Easily adjustable soft-grip handle for optimum comfort.
Powerful and Efficient X-TORQ® Engine
The X-Torq® engine design reduces harmful exhaust emissions by up to 60% and increases fuel efficiency by up to 20%.
| Vibration | 535LK SKU: 967 68 81‑04 |
| Equivalent vibration level (ahv, eq) front handle | 4.5 m/s² |
| Equivalent vibration level (ahv, eq) rear handle | 3.9 m/s² |
| Capacity | |
| Cutting width | 17.7 in |
| Dimensions | |
| Weight (excl. cutting equipment) | 12.79 lbs |
| Product size length | 70.3 in |
| Product size width | 10 in |
| Tube length | 58.386 in |
| Product size height | 9.8 in |
| Tube diameter | 0.94 in |
| Emission | |
| Exhaust emissions (CO average) | 418.31 g/kWh |
| Exhaust emissions (CO average) | 243.69 g/kWh |
| Exhaust emissions (CO average) | 243.69 g/kWh |
| Engine | |
| Cylinder displacement | 2.11 cu.inch |
| Power output | 2 hp |
| Maximum power speed | 8,400 rpm |
| Fuel tank volume | 20.29 fl oz |
| Fuel consumption | 475 g/kWh |
| Idling speed | 2,900 rpm |
| Spark plug | Champion RCJ6Y |
| Electrode gap | 0.02 in |
| Torque, max. at rpm | 6,600 rpm |
| Torque, max. | 1.9 Nm |
| Clutch engagement speed (±120) | 4,300 rpm |
| Maximum rpm output shaft | 8,013 rpm |
| Equipment | |
| Trimmer head | T35 M10 |
| Lubricant | |
| Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 |
| Sound and Noise | |
| Sound pressure level at operators ear | 99 dB(A) |
| Sound power level, guaranteed (LWA) | 114 dB(A) |
| Transmission | |
| Gear ratio | 1 |
| Drive gear angle | 30 ° |
