Intuitive Controls
Digital ignition for simple, reliable use no matter the weather
Smart Start® Technology
Specially-designed engine and starter for easy and fast starting with minimum effort
Quick Start with Air Purge
Air purge removes air from carburetor and fuel system for easy starting
Simple Starting
Stop switch automatically resets to ON so trimmer is ready for next use
Ergonomic Design
Comfortable curved handle and shaft for easier use and increased maneuverability
High Line Capacity
Tap 'n' Go trimmer head is easy to use and refill
LowVib® Technology
Dampeners between the engine and chassis significantly reduce vibrations so you can work more comfortably
| Vibration | 130C Art no: 970 51 43‑02 |
| Equivalent vibration level (ahv, eq) front handle | 4.61 m/s² |
| Equivalent vibration level (ahv, eq) rear handle | 5.65 m/s² |
| Capacity | |
| Cutting width | 17 in |
| Dimensions | |
| Weight (excl. cutting equipment) | 11.3 lbs |
| Product size length | 60 in |
| Product size width | 11 in |
| Tube length | 50.315 in |
| Product size height | 15 in |
| Tube diameter | 0.945 in |
| Emission | |
| Exhaust emissions (CO average) | 0 g/kWh |
| Exhaust emissions (CO average) | 128.59 g/kWh |
| Exhaust emissions (CO average) | 70.32 g/kWh |
| Engine | |
| Cylinder displacement | 1.7 cu.inch |
| Power output | 1 hp |
| Maximum power speed | 8,000 rpm |
| Fuel tank volume | 17.82 fl oz (US) |
| Fuel consumption | 543 g/kWh |
| Idling speed | 3,000 rpm |
| Spark plug | Champion QCJ-8Y |
| Electrode gap | 0.02 in |
| Torque, max. at rpm | 7,000 rpm |
| Torque, max. | 0.95 Nm |
| Clutch engagement speed (±120) | 4,200 rpm |
| Maximum rpm output shaft | 10,500 rpm |
| Equipment | |
| Grass blade | Not included |
| Harness | Not included |
| Trimmer head | T25 (L) |
| Saw blade | Not included |
| Lubricant | |
| Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 |
| Sound and Noise | |
| Sound pressure level at operators ear | 97 dB(A) |
| Sound power level, guaranteed (LWA) | 116 dB(A) |
| Transmission | |
| Gear ratio | 1 |
| Drive gear angle | 0 ° |
