Features
PERFORMANCE FEATURES
- Heavy duty augers equipped with double flighting for more cutting surfaces and faster digging
- Special alloy pinion gears and tapered roller bearings on both sides of each gear
CONSTRUCTION FEATURES
- 2400 Series model fits both Cat. 1 and Cat. 2 tractors
- Offered in both regular duty and heavy duty augers in sizes from 6-inch to 12-inch
- Rugged gearbox construction
- Shear pin driveline protection
- Options include Hydraulic Down Force Kit, Parking Stand, and Auger Extensions
PRODUCT FEATURES
- 2” Round hub connection
- Replaceable drill teeth
- Heavy duty augers equipped with double flighting for more cutting surfaces and faster, easier digging—especially in heavier soils
- Rugged gearbox construction
- Special alloy pinion gears and tapered roller bearings on both sides of each gear
- Shear pin driveline protection
Specs
| Specification | PHD2401 |
| Auger Length | 42” RD/48” HD |
| Auger Diameter | 6 in., 9 in. or 12 in., Reg. Duty and Heavy Duty |
| Auger RPM | 180 |
| Type Hitch | Cat. I and II |
| Input RPM | 540 |
| Gear Ratio | 3.00:1 |
| Output Shaft | 2 in. Diameter |
| Driveshaft | ASAE Cat. I |
| Hitch Yoke | 2- 7/8 in. tubing |
| Boom | 2- 7/8 in. tubing |
| Component Protection | Shear bolt |
| Options (All Models) | Hydraulic Down Force Kit / Parking Stand / Auger Extensions |
