1025 Sub-Compact Tractor Features & Benefits

FEATURING:

  • 25 HORSEPOWER
  • 992 LBS. LOADER LIFT CAPACITY AT PINS
  • HYDRO MAX TRANSMISSION
  • DUAL HST PEDALS
  • 2 RANGE TRANSMISSION



ADDITIONAL FEATURES

  • INDEPENDENT PTO
  • POWER STEERING
  • SELECTABLE 4WD
  • DIFFIRENTIAL LOCK
  • 7 YEAR POWERTRAIN WARRANTY

1025 Sub-Compact Tractor Specs & Compare

1025 Engine
Engine3 Cylinder, Water-Cooled, Diesel
Engine HP @ RPM24.6
Displacement (in.)77.3
Number Of Cylinders3
Fuel Tank (gal.)5.8
1025 Drivetrain
TransmissionHST
Number Of Speeds2 Range
ClutchNo
BrakesWet, Multi-Disc
1025 Hydraulics
TypePower Assisted Hydro-Static
Total Hydraulic Flow (Power Steering + Implement)7.0 (2.8+4.2) / 25.7 (10.5+15.8)
3-Point HitchCat 1
Rear Remote ValveN/A
3-Point Hitch Lift Capacity @ 24" Behind Lift Point (lbs.)1101
1025 Dimensions
Overall Length104"
Overall Width45.8"
Overall Height91.3"
Wheelbase57.5"
Minimum Ground Clearance9.4"
Weight1,638 lbs.
1025 PTO
TypeIndependent
Rear (Mid) PTO Speed540
PTO HP18.8
1025 Electrical
Battery12 V, 500 CCA
Alternator12 V, 40 A
1025 Wheels & Tires
IND (Front)23X8.50-12
IND (Rear)12-16.5
1025 Loader - Model BBL105
Standard Bucket Size (in.)50
Maximum Lift Height (in.)75.5
Dig Depth (in.)4.6
Lift Capacity To Full Height At Pivot Pin (lbs.)992
Breakout Force (lbs.)1,531
Shipping Weight (lbs.)573
1025 Backhoe - Model BBH105
Standard Bucket Size (in.)12
TypeSubframe-Mounted, Quick Attach
Maximum Dig Depth (in.)76
Dig Force Bucket (lbs.)2,020
Shipping Weight (lbs.)816
