Features
Heavy-Duty Fabricated Deck
11 ga. fabricated steel deck with reinforced steel along the trim edge.
Heavy-Duty Frame
1" x 2" heavy-duty one-piece frame puts it at the top of the category.
Sealed AGM Batteries
Up to 90 minutes of run time with 6-hours for complete charge, the 48v battery system contains four 12v batteries. LED indicator prominently displays battery life.
Charge Time
The AGM battery system is fully charged in six hours. Charger can be plugged into any standard electrical outlet. No special connection required.
Compact Design
Easily fits through most gates making backyard mowing easy and ideal for garage storage.
BigBite Drive Tires
Industry exclusive 18" BigBite rear drive tires.
Specs
| KEY SPECS | |
| BATTERY TYPE | AGM |
| BATTERY VOLTAGE | 48v System (4 - 12v batteries) |
| TRANSMISSION | Dual brushless motor with gear reduction |
| FUEL CAPACITY | n/a |
| GROUND SPEED (FWD) | Up to 7 mph (5 mph low) |
| CUTTING WIDTH | 42" |
| CUTTING HEIGHT | 1.5" to 4.5" |
| FRONT TIRE | 11 X 6 |
| DRIVE TIRE | 18 X 8.5 - 8 BigBite™ |
| BATTERY | |
| BATTERY TYPE | AGM |
| BATTERY VOLTAGE | 48v System (4 - 12v batteries) |
| CHARGE TIME | 6 Hours |
| WATT HOURS | 5040wh |
| BATTERY GAUGE | LED indicator |
| START METHOD | Key switch |
| DRIVE SYSTEM | |
| TYPE | n/a |
| TRANSMISSION | Dual brushless motor with gear reduction |
| HYDRAULIC LINES | n/a |
| RESERVOIR CAPACITY | n/a |
| HYDRAULIC COOLING | n/a |
| FUEL CAPACITY | n/a |
| GROUND SPEED (FWD) | Up to 7 mph (5 mph low) |
| PARKING BRAKE | Foot operated |
| DECK | |
| CUTTING WIDTH | 42" |
| CUTTING HEIGHT | 1.5" to 4.5" |
| DECK DEPTH | 4.1" |
| DECK LIFT | Foot Operated |
| NUMBER OF BLADES | 2 |
| BLADE LENGTH | 20.50" |
| BLADE TIP SPEED | 16,637 |
| SPINDLES | Dual electric brushless motor |
| DECK ENGAGEMENT | n/a |
| DECK MATERIAL | Fabricated 11 gauge steel |
| SPINDLE MOUNTS | Reinforced 14 gauge steel |
| IMPACT TRIM AREA | 1/4" x 3/4" steel bar |
| ANTI-SCALP WHEELS | n/a |
| CONSTRUCTION | |
| FRAME | 1" X 2" steel tubing |
| ENGINE PLATE | n/a |
| OPERATOR PLATFORM | n/a |
| FRONT AXLE | Fabricated with sealed ball bearings |
| FRONT CASTER WHEEL | Sealed ball bearings |
| FRONT CASTER FORK | Fabricated 1/4" steel |
| GENERAL | |
| SEAT | Premium bolstered seat with built-in lumbar support |
| CUP HOLDER | Yes |
| DIMENSIONS | |
| FRONT TIRE (INCHES) | 11 X 6 |
| DRIVE TIRE (INCHES) | 18 X 8.5 - 8 BigBite™ |
| WING TIRE (INCHES) | n/a |
| WEIGHT (LBS) | 655 |
| HEIGHT (INCHES) | 40 |
| LENGTH (INCHES) | 65.5 |
| WIDTH W/ CHUTE UP (INCHES) | 43.5 |
| TIRE-TO-TIRE WIDTH (INCHES) | n/a |
| PRODUCTIVITY (ACRES PER HOUR) | Run Time per Charge: Up to 3.6 acres or 90 minutes |
| DIMENSIONS WITH CATCHER | |
| CATCHER STYLE | Side Catcher |
| POWERED / NON-POWERED | Non-powered |
| CATCHER CAPACITY | 2 bushel |
| MOWER LENGTH W/ CATCHER | n/a |
| MOWER WIDTH W/ CATCHER | n/a |
Accessories and Attachments
Side Grass Bagger
Mesh side-bagger holds 2 bushels.
Fits:
Dash
Dash XD
Zevo
Mulch Kit
Recycle clippings back into the soil and reclaim nutrients for your lawn.
Fits:
Dash
Raptor X
Raptor XL
Raptor XD
Raptor XDX
Flip-Up
Dash XD
Zevo
Surfer Pro
Light Kit
Extend your productivity into the late hours with our optional light kit.
Fits:
Dash
Raptor X
Raptor XL
Raptor XD
Raptor XDX
Flip-Up
Dash XD
Zevo
Steering Lever Extension Kit
Allows height adjustment of steering levers to make your mowing experience as comfortable as possible.
Fits:
Dash
Dash XD
Raptor X
Raptor XL
Raptor XD
Raptor XDX
Flip-Up
Zevo
Armrest Kit
Provides more comfort while you mow.
Fits:
Dash XD
Zevo
USB Kit
A kit for adding a usb port to your mower.
Fits:
Raptor X
Raptor XL
Raptor XD
Raptor XDX
Zevo
Stripe Kit
Helps provide a professional manicured finish to your lawn.
Fits:
Raptor X
Raptor XL
Raptor XD
Raptor XDX
Dash
Dash XD
Zevo
