Features
The heavy-duty expeller system with a quick release poly-lined fine spread pan, and side fins help cut the drift of material towards the tractor and spreader, and provide an excellent spread pattern.
- 40″ Wide “Top Shot” Expeller Beater
- 30″ Diameter Round Core Segmented Auger
- Heavy Duty Gearbox Reduction
- Overrunning Clutch /Torque Limiting Clutch
- Left Side Poly Lined Tank
- Front and Rear Splash Guards
- Flip-Over Adjustable Hitch
- Shear Bolt Protection
- The auger System hydraulically raise and lower a full 8″ to break-up material that may bridge during the unloading process.
- Automatic Chain Oiler System
- Highway Lighting System
- Remote Grease System
- Hydraulic Lid (Optional)
Specs
| MODEL | 5242 |
| CUBIC FT. STRUCK LEVEL | 564 |
| GALLON CAPACITY | 4200 |
| TANK LENGTH | 20′ |
| OVERALL LENGTH | 27′ 7″ |
| TANK WIDTH - TOP | 97″ |
| AUGER DIAMETER | 30″ |
| POLY LINED TANK | Left Side |
| OVERRUNNING CLUTCH | Yes |
| SHEAR BOLT PROTECTION | Yes |
| PTO | 1000 RPM 1 ¾″ Std. or 1000 RPM 1 ⅜″ Opt. |
| EXPELLER WIDTH | 40″ |
| FRONT SPLASH-GUARDS | Standard |
| REAR SPLASH-GUARDS | Standard |
| AUTOMATIC OILER | Standard |
| HIGHWAY LIGHTING | Standard |
| WEIGHT | 16,500# |
| TIRE SPECIFICATIONS | w/28L X 26 |
| SIDE LOADING HEIGHT | 93″ |
| HEIGHT @ REAR CYL. BRACKET | N/A |
| HEIGHT @ FRONT SPLASH | 101″ |
| HEIGHT @ REAR SPLASH | 101″ |
| OVERALL WIDTH | 125″ |
