Features
ALL MODELS EXCEPT THE 5215 are available with the optional Digi-Star GT400, or Nutrient Tracker Scale System with GPS!
The heavy-duty expeller system with a quick release poly-lined fine spread pan, and side fins help cut the drift of material towards the tractor and spreader, and provide an excellent spread pattern.
- 40″ Wide “Top Shot” Expeller Beater
- 24″ Diameter Round Core Segmented Auger
- Left Side Poly Lined Tank
- Front and Rear Splash Guards
- Flip-Over Adjustable Hitch
- Overrunning Clutch /Torque Limiting Clutch & Shear Bolt Protection
- Shear Bolt Protection
- The auger System hydraulically raise and lower a full 8″ to break-up material that may bridge during the unloading process.
- Automatic Chain Oiler System
- Highway Lighting System
- Remote Grease System
Specs
| MODEL | 5226 |
| CUBIC FT. STRUCK LEVEL | 347 |
| GALLON CAPACITY | 2596 |
| TANK LENGTH | 16′ |
| OVERALL LENGTH | 22′ 8″ |
| TANK WIDTH - TOP | 87″ |
| AUGER DIAMETER | 24″ |
| POLY LINED TANK | Left Side |
| OVERRUNNING CLUTCH | Yes |
| SHEAR BOLT PROTECTION | Yes |
| PTO | 540 RPM Std. 1000 RPM Opt. |
| EXPELLER WIDTH | 40″ |
| FRONT SPLASH-GUARDS | Standard |
| REAR SPLASH-GUARDS | Standard |
| AUTOMATIC OILER | Standard |
| HIGHWAY LIGHTING | Standard |
| WEIGHT | 7,880# |
