Features
ALL MODELS EXCEPT THE 5215 are available with the optional Digi-Star GT400, or Nutrient Tracker Scale System with GPS!
The heavy-duty expeller system with a quick release poly-lined fine spread pan, and side fins help cut the drift of material towards the tractor and spreader, and provide an excellent spread pattern.
- 30″ Wide “Top Shot” Expeller Beater
- 24″ Diameter Round Core Segmented Auger
- Left Side Poly Lined Tank
- Front Splash Guards
- Overrunning Clutch /Torque Limiting Clutch & Shear Bolt Protection
- Shear Bolt Protection
- Remote Grease System
- The Auger System hydraulically raise and lower a full 8″ to break-up material that may bridge during the unloading process.
- Automatic Chain Oiler System (Optional)
- Highway Lighting System (Optional)
- Rear Splash Guard & Side Boards = 1500 Gallon Capacity (Optional)
- Tandem axle is available with your choice of 295R x 225 recap tires or 16.5 x 16.1 floatation tires. (Optional)
Specs
| MODEL | 5215 |
| CUBIC FT. STRUCK LEVEL | 172 |
| GALLON CAPACITY | 1286 |
| TANK LENGTH | 14′ |
| OVERALL LENGTH | 20′ 10″ |
| TANK WIDTH - TOP | 70″ |
| AUGER DIAMETER | 24″ |
| POLY LINED TANK | Left Side |
| OVERRUNNING CLUTCH | Yes |
| SHEAR BOLT PROTECTION | Yes |
| PTO | 540 RPM Std. 1000 RPM Opt. |
| EXPELLER WIDTH | 30″ |
| FRONT SPLASH-GUARDS | Standard |
| REAR SPLASH-GUARDS | Optional |
| AUTOMATIC OILER | Optional |
| HIGHWAY LIGHTING | Optional |
| WEIGHT | 5,740# |
