Features
- All welded heavy duty A-frame hitch assembly and full length unitized main frame.
- Heavy duty 2-speed apron drive system plus beater shutoff for a positive drive and long life.
- A heavy duty beater assembly assures aggressive shredding action with even wide spread patterns.
- Spreader box sides are constructed of corrosion resistant galvanized steel.
- Main apron tightener bolts are located outside on the lower right and left corners of the main frame.
Specs
| 2217 | |
|---|---|
| CAPACITY – HEAPED (OLD RATING) BU. | 175 bu. |
| CAPACITY – CU. FT. STRUCK LEVEL | 105 |
| TOP OF FLARE WIDTH | 63 ½″ (161 cm) |
| INSIDE WIDTH | 54″ (137 cm) |
| INSIDE LENGTH | 11′ 1″ (338 cm) |
| INSIDE DEPTH | 25 ¾″ (65 cm) |
| OVERALL LENGTH | 17′ 8″ (538 cm) |
| OVERALL LOADING HEIGHT – TOP OF FLARE | 45 ½″ (116 cm) |
| OVERALL HEIGHT W/HYD. ENDGATE | 49″ |
| OVERALL WIDTH W/STANDARD TIRES | 83 ½″ (212 cm) |
| STANDARD TIRE SIZE | 9.00 x 20 |
| SPINDLE SIZE | 2″ (5 cm) |
| DIAMETER OF BEATER | 27″ (68 cm) |
| NUMBER OF PADDLES | 8 |
| MAIN APRON CHAIN | T-rod |
| BOX CONSTRUCTION | Powder Coated Steel |
| FLOOR CONSTRUCTION | Bonded Poly |
| APRON DRIVE | Gearbox 2 Speed PTO |
| UPPER BEATER | OPTIONAL |
| SWING AWAY JACK | STANDARD |
| WEIGHT W/TIRES | 2030 lbs. (921 kg) |
| OPTIONS | FINE SPREAD PAN – HYD. END GATE |
