Features
Standard Equipment
- PTO or engine driven hydraulic pump
- Self-contained hydraulic system
- Full hydraulic controls
- Large hammer face
- Hammer ballast box with lid
- Welded frame, axle and counter weight box reduces set up time
- Rear stand to prevent backward flip over
Optional Equipment
- Mast extension
- Hydraulic extendable hitch
- 2" ball hitch receiver
- 6.70 x 15 4-ply bias tires
- Post guide
- Post rack
Specs
| Model | 2400, Engine or PTO Drive |
| Frame | All welded tubular steel construction |
| In frame counterweight box | 15" x 15" x 25" - 3.2 cu. ft. (92L) |
| Wheel track width | 69" (1750 mm) |
| Wheel rims | 15" (381 mm) (6.70 x 15 4-ply bias tires optional) |
| Wheel bearings | Tapered roller |
| Mast | 12" (305 mm) wide track |
| Hammer weight | 310 lb (141 kg) empty, up to 700 lb (318 kg) ballasted |
| Impact at full stroke | 100,000 lb (45,360 kg)* |
| Maximum hammer height | Standard lift 105" (2.67 m), 128" (3.25 m) with optional mast extension |
| Minimum hammer height | 43" (1090 mm), 66" (1676 mm) with optional mast extension |
| Maximum hammer stroke | 62" (1570 mm) |
| In & out hammer slide | 16" (410 mm) |
| Hammer tilt, from vertical | Fore 20° / Aft 15°, Side Tilt: Left 40° / Right 22° |
| Basic shipping weight | PTO: 1190 lb (540 kg), Engine: 1300 lb (590 kg) |
