Features
Product Features:
- Grapple opening of 44” – fully usable, no trapped space
- Lids are uniform between our Worx Duty root grapple and Worx Duty grapple bucket line
- Standard reversible front bolt-on cutting edge
- Maximum clamping force of 3,600 lbs @ 3,000 psi
- A pair of 3/16” load transfer plates eliminates flex between the moldboard and hinge frame
- Radius moldboard for strength and easy unloading
- 5/8” x 6” bolt-on reversible cutting edge on 60”-82”
- ½” lid tines on 1¼” pivot pins with robust broken-out lid decks for strength
- Covered hoses for full protection in harsh environments
- Models include 60”, 67” , 73” and 82”
Designed for:
- For skid steer loaders and compact track loaders with 51 - 100 horsepower
- Enables operator to move hard-to-handle materials, as well as brush and other awkward debris
- Compliment to our popular Worx Duty root grapple line
Specs
| Model | 1GBWX |
| Item | 1GBWX60 , 1GBWX67 , 1GBWX73 , 1GBWX82 |
| Product Category | Grapple Bucket |
| Duty Rating | Worx Duty |
| Width (Inches) | 60, 67, 73, 82 |
| Max Grapple Opening (IN) | 44 |
| Weight (LBS) | 1000 - 1,222 |
| Attachment Options | None |
| OEM Colors Available | Yes |
| Designed For Use | aggressive applications, industrial, landscaping, agriculture, carrying, demolition |
| Suitable For | Skid Steers, Compact Track Loaders |
