D60X90 S3 HDD Features & Benefits

Increased power

Up to 60,000 lb (226.9 kN) of thrust and pullback and 9,250 ft-lb (12,202.4 Nm) of rotational torque helps you get the job done faster.

Significant sound reduction

Guaranteed sound power rating of just 107 dB(A) – 12 dB(A) lower than its predecessor the D60x90 – resulting in reduced noise at operator’s ear [83 dB(A)], increased operator comfort and minimized noise disturbance in residential or urban areas.

DigiTrak® Aurora® touchscreen display

Interactive, full-color DigiTrak® Aurora® touchscreen display allows operators to load the bore plan via flash drive and view it on screen — eliminating hard copy plans.

Large open-top vise

Large open-top vise design allows passage of larger tooling for ease of tool removal and installation.

Convenient rod loading

Popular and proven rod loader design provides reliable performance.

D60X90 S3 HDD Specs & Compare

General Dimensions and Weights
Length (Minimum Transport)354 in
Width (Minimum Transport)90 in
Height (Minimum Transport)104 in
Height (With Cab)104 in
Weight42150 lbs
Angle of Approach18 deg
ENGINE
Make and ModelCat
Fuel TypeUltra Low Sulfur Diesel
Maximum Engine RPM2200 rpm
Gross Horsepower202 hp
AspirationTurbo Charged
OPERATIONAL
Thrust60000 lbs
Pullback60000 lbs
Maximum Carriage Speed at Maximum Engine RPM175 ft/min
Maximum Carriage Speed in Low at Maximum Engine RPM55 ft/min
Maximum Spindle Torque (Low at Maximum Engine RPM)9250 ft-lb
Maximum Spindle Torque (Medium at Maximum Engine RPM)6810 ft-lb
Maximum Spindle Torque (High at Maximum Engine RPM)3790 ft-lb
Maximum Spindle Speed at Max Engine RPM200 rpm
Minimum Bore Diameter6 in
Maximum Ground Drive Speed at Maximum Engine RPM3.7 mph
Automated Rod LoaderYes
Noise Level at Operator's Ear83 dB(A)
FLUID CAPACITIES
Fuel Tank90 gal
Hydraulic Tank75 gal
Hydraulic System100 gal
HYDRAULIC SYSTEM
Auxiliary Pump Flow at Maximum Engine RPM13.4 gpm
Auxiliary Pump Relief Pressure3000 psi
Thrust/Pullback Pump Flow at Max Engine RPM41 gpm
Thrust/Pullback Pump Relief Pressure5500 psi
Rotation Pump Flow at Maximum Engine RPM55 gpm
Rotation Pump Relief Pressure5800 psi
DRILLING FLUID SYSTEM OPTION ONE
Maximum Flow150 gpm
Maximum Pressure900 psi
BrandKerr
FEATURES
Breakout SystemOpen top Vise
Drilling LightsStandard
Flow IndicatorStandard
Stakedown SystemTwo Options
CabStandard
Strike AlertStandard
Remote LockoutStandard
Operator PresenceStandard
