D20X22 S3 HDD Features & Benefits

Install more in each day

A newly designed hydraulic circuit offers additional power for drilling and maneuvering around the jobsite, helping operators power up curbs and slopes to work more efficiently.

The 3.3-mph (5.3-km/hr) tracking speed gets you from one setup to the next sooner.

The class-leading 167-fpm (50.9-m/min) carriage speed and rotational speeds of 257 rpm help you install more linear feet per day.

Straightforward control and operation

Simplify machine monitoring with onboard diagnostics.

Common dual joysticks on the current Vermeer drill lineup assist in operator efficiency and training.

Your access to MORE: VermeerOne™

VermeerOne™ Platform isn’t just a tool or platform. It’s an experience — one designed to simplify equipment management, empower users with real-time data to make smarter decisions, and help maximize productivity and profitability.

D20X22 S3 HDD Specs & Compare

General Dimensions and Weights
Length (Minimum Transport)204 in
Width (Minimum Transport)47.5 in
Height (Minimum Transport)74 in
Weight11700 lbs
Angle of Approach18 deg
Engine
Make and ModelDeutz TD2.9
Fuel TypeLow sulfur diesel
Maximum Engine RPM2600 rpm
Gross Horsepower74 hp
Displacement177 cu-in
AspirationTurbo charged
Cooling MethodLiquid
Noise Level at Operator's Ear86.5 dB(A)
Emissions ratingTier 4i (EU Stage IIIA)
ENGINE OPTION TWO
Make and ModelDeutz TD2.9
Fuel TypeUltra-low sulfur diesel
Maximum Engine RPM2600 rpm
Gross Horsepower74 hp
Displacement177 cu-in
AspirationTurbocharged
Cooling MethodLiquid
Noise Level at Operator's Ear86.5 dB(A)
Emissions ratingTier 4 Final (EU Stage IV)
ENGINE - OPTION THREE
Make and ModelDeutz TD2.9
Fuel TypeUltra-low sulfur diesel
Maximum Engine RPM2600 rpm
Gross Horsepower74 hp
Displacement177 cu-in
Cooling MethodLiquid
AspirationTurbocharged
Noise Level at Operator's Ear91 dB(A)
Emissions ratingTier 4 Final (EU Stage V)
Operational
Thrust19500 lbs
Pullback19500 lbs
Maximum Carriage Speed at Maximum Engine RPM160 ft/min
Maximum Carriage Speed in Low at Maximum Engine RPM114 ft/min
Maximum Spindle Torque (Low at Maximum Engine RPM)2250 ft-lb
Maximum Spindle Speed at Max Engine RPM257 rpm
Minimum Bore Diameter3 in
Maximum Ground Drive Speed at Maximum Engine RPM3.3 mph
Automated Rod LoaderSemi-automated
Guaranteed sound power (CE-rating)106 dB(A)
Drill Rack Angle17 deg
DRILLING FLUID SYSTEM OPTION ONE
Maximum Flow25 gpm
Maximum Pressure1000 psi
FEATURES
Breakout SystemStandard hydraulic vice
Drilling LightsOptional
Flow IndicatorStandard
Stakedown SystemStandard
Strike AlertStandard
Remote LockoutStandard
Operator PresenceStandard
