Chews through a lot
The 48-hp (36-kW) diesel engine delivers optimal fuel economy, durability and performance for efficient stump cutting of all sizes.
This direct-drive system delivers the maximum amount of power to the cutter wheel and requires minimal maintenance.
Exclusive SmartSweep control system monitors engine load, providing continuous feedback for a smooth, consistent cutter wheel sweep rate, maximizing efficiency and productivity while minimizing machine wear and tear.
With exceptional straight-line cutting dimensions, the SC48TX can tackle stumps big and small efficiently, with minimal need for repositioning.
Jobsite flexibility
Options for both the Vermeer cutting system (VCS) or Yellow Jacket™ cutter system give you the choice to select the wheel that is right for your operation and ground conditions.
Optional chip blade efficiently moves chips around the jobsite, reducing the need for manual relocation. Its design allows easy access through narrow gates and travel on uneven terrain, while minimizing turf damage.
Optional remote control enables operation of the machine from a distance and enhances jobsite visibility.
Operator safety
The swing out control station helps protect the operator from thrown objects while providing optimal visibility at the stump.
The operator presence system allows the cutter wheel to automatically stop when the operator releases the hydraulic cutter wheel controls.
Your access to MORE: VermeerOne™
VermeerOne™ Platform isn’t just a tool or platform. It’s an experience — one designed to simplify equipment management, empower users with real time data to make smarter decisions, and help maximize productivity and profitability.
| GENERAL DIMENSIONS AND WEIGHTS | |
| Length | 140 in |
| Width (tracks retracted) | 35 in |
| Width (tracks extended) | 49 in |
| Height (non-remote unit) | 76 in |
| Height (remote unit) | 85 in |
| Weight - Engine Option One | 3750 lbs |
| Sound Power | 107 dB(A) |
| ENGINE - OPTION ONE | |
| Make and Model | CAT C1.7 T4F/Stage V |
| Number of Cylinders | 3 |
| Gross Horsepower (Maximum) | 48 hp |
| Torque (Max) | 123 ft-lb |
| Fuel Tank Capacity | 14.5 gal |
| Max Fuel Consumption | 2.9 gph |
| Fuel Type | Ultra-low sulfur diesel |
| Air Cleaner | Dry-type, restriction indicator, evacuator valve and safety element |
| Oil Filter | Spin-on |
| Recommended Oil | 10W-30 |
| Oil Volume with Filter | 5.3 qt |
| Maximum Angle of Continuous Operation | 35 deg |
| Cooling Medium | Water/antifreeze |
| Coolant Capacity (Engine and Radiator) | 2.9 gal |
| Alternator | 85A |
| Fan | 16.5 in |
| Clutch Type | Electric clutch with brake |
| CUTTERWHEEL SYSTEM | |
| Cutterwheel Diameter | 24 in |
| Cutterwheel Thickness | 1.4 in |
| Cutterwheel Speed | 1235 rpm |
| Cutterwheel Straight Line Dimension | 65 in |
| Cutterwheel Cut Above Ground | 28 in |
| Cutterwheel Cut Below Ground | 16 in |
| Tooth Description | Vermeer cutting system |
| Number of Teeth | 27 |
| Number of wear plates | 6 |
| Reversible Pockets/Teeth | 24 |
| Cutterwheel Guard | Standard |
| Chip Containment | 23 cu ft |
| CUTTERWHEEL DRIVE COMPONENTS | |
| Lower Gearbox | Straight bevel |
| Oil Type - Lower Gearbox | SAE 75W90 synthetic gear oil |
| Oil Capacity - Lower Gearbox | 1.6 qt |
| Driveshaft | 2 universal joints |
| Driveshaft - U Joints | 2 standard with double lip seal |
| HYDRAULIC SYSTEM | |
| Tank capacity | 9 gal |
| Recommended Oil Type | Vermeer highpower 68 |
| System Type | Tandem gear pump, pressure balanced |
| Filtration Method | Full-flow 4-micron return filter, suction strainer |
| Pump Flow at Maximum RPM | 11 gpm |
| System relief pressure | 2900 psi |
| Directional Control | Yes |
| Oil Cooler | Yes |
| ELECTRICAL SYSTEM | |
| System Voltage | 12 |
| Battery | 950 CCA |
| Warning Lights | Engine warning |
| Switches | Boom swing, boom height, creep propel, ignition, clutch, track gauge, track speed range and throttle, blade |
| Controller | Danfoss |
| Display | Multifunction display (MFD) that displays hours, fuel level, engine speed, engine faults and engine status |
| Shutdown System | High engine temperature and low oil pressure |
| Radio Remote Control | Optional, wireless |
| CHASSIS | |
| Frame Description | Welded tube and plate steel |
| Control Station Description | Swing out |
| Operator Vision Shield Description | Abrasion-resistant coated polycarbonate |
| Brake Type | Spring-applied and hydraulically-released dual parking brakes |
| TRACK DRIVE SYSTEM | |
| Track Type | Rubber 7-in width |
| Track Length on Ground | 47 in (119.4 cm) |
| Type of Idler | Cast |
| Number of Idlers | 7 |
| Track Drive Pump Type | Tandem gear pump, pressure balanced |
| System Relief Pressure | 2900 psi |
| High Speed Travel | 1.5 mph |
| Low Speed Travel | 1.1 mph |
| Ground Bearing Pressure - Soft Ground | 5.7 psi |
| GROUND DRIVE | |
| Low Speed Travel | 100 ft/min |
| High Speed Travel | 140 ft/min |
| OPTION ONE | |
| Chip blade width (without extensions) | 34 in |
| Blade Travel Above Ground | 8.5 in |
| REMOTE CONTROL OPTION | |
| Radio Remote Control | Optional |
| Remote Functions | E-stop, throttle, cutter wheel clutch, boom swing, boom height, propel, track mode and track speed range |
| Remote Display | LCD with remote control and machine functions status |
| Remote Range | 300 ft (91.4 m) |
| OTHER OPTIONS | |
| Special Paint | Optional |
| Extended Warranty | Optional |
| Preventive Maintenance | Optional |
