Features
| Features | Benefits |
| 540 rpm Cat l & ll three-point mounting | Adapted for service on a wide range of tractors. |
| Low horsepower requirements | 52 Horsepower requirement for approximately 25 gpm @ 3000 PSI and 540 rpm |
| 35 Gallon self contained reservoir with 10 micron filter | Provides more than ample amounts of clean and cool hydraulic fluid for even the most demanding applications. |
| Steel construction on Hydraulic Tank | Provides for long service life in harsh environments. |
| Standard reversing solenoid | Allows powered implements, motors, and cylinders to be reversed for expanded range of performance capabilities. |
| Standard pressure relief valve | Protects hydraulic system from overloads or unanticipated stalls. |
| Standard case drain port | Enables attachment and usage with implements equipped with and requiring case drain return lines. |
| Standard compliment of hydraulic fittings & two 23'-9" of hydraulic hoses supplied | Enables ready attachment and adaptation to a wide range of tractors and applications. |
| Multi-functional electronic remote tether control | Enables forward and reverse continuous flow or intermittent forward or reverse flow from the tractor seat or on the ground. |
| Driveline connected | Easy hook-up to rear PTO tractor shaft. |
| Oil cooler | For oil cooling when necessary. Included with hand valve & solenoid valve options. Optional with no valve option. |
| Integral storage stands | Provides for easy installation and removal from the tractor and clean and convenient long term storage. |
Specs
| Model | HRS3025 |
| Minimum tractor horsepower | 52 hp |
| Maximum hydraulic horsepower output | 43 hp |
| Pump capacity | Approx. 25 gpm @ 540 rpm at 3000 PSI |
| PTO input speed | 540 rpm |
| Hydraulic fluid type | Mobil Fluid 424 (See www.mobil.com for alternate fluids) |
| Reservoir capacity | 35 Gallons |
| Filter type | LE 10 Micron filter |
| Oil level check | Oil fill cap with dipstick |
| Overload protection | Hydraulic relief valve |
| Hitch | 3-Point Cat. l & ll with clevis style lower hitch, Quick hitch adaptable |
| Driveline | ASAE Category 2 |
| Pressure & return hose lengths | 24 Feet each |
| Case drain port | 3/4"-16 UNF |
| Optional & Accessory Equipment | |
| Flow control Option | No Valve No Cooler (Pressure relief valve provided for protection) |
| Option | No Valve With Cooler (Pressure relief valve provided for protection) |
| Option | Manual Operated Valve With Oil Cooler (Pressure relief is built into the valve) |
| Option | Solenoid Operated Valve With Oil Cooler (Pressure relief is built into the valve) |
| Small flat face couplers Option | 1/2" body size (Includes adapter for attaching to hoses with 1 5/16" threads) |
| Large flat face couplers Option | 3/4" body size (Attach to hoses with 1 5/16" threads) |
| Case drain kit Option | Complete with 3/4" MORB x 9/16" MJIC elbow, 23'-9" of 3/8" hydraulic hose, and one 3/8" body flat face low spill quick coupler male tip |
