Features
| Features | Benefits |
| Fits Kubota’s BX80 Series tractors with Model LA340S or LA344S loader and universal quick attach hitch |
Easy to hook-up. A good fit for Kubota BX80 Series tractors with a universal quick attach hitch on the front of the loader. |
| Designed to protect hydraulic hoses | Hydraulic hoses routed to prevent pinching. |
| 3/4" Pivot pins | Large diameter pins for extra strength. |
| Dual hydraulic cylinders | Allows upper claw to grip the material better. |
| AR400 teeth material | Four times the strength of mild steel. |
| High volume cage design | Can handle large volume of material. |
| (Optional) BX80 third function quick connect male couplers |
Attaches to Kubota’s Model LA340S or LA344S loader 3rd function valve ports to complete hydraulic hose hook-up. Hydraulic hook-up is made easy with hose hook-up located at the front of the loader. |
Specs
| Model | SGC0554 |
| Tractor requirements: Horsepower Weight |
17-26 hp 1300-1600 lbs |
| Grapple weight | 180 lbs. |
| Hitch Type | Universal quick attach hitch |
| Overall width | 54" |
| Closed height | 26 1/2" |
| Jaw opening | 30" |
| Number of teeth | 6 Lower teeth & 7 upper teeth |
| Bottom teeth spacing | 5 spaces at 10 3/4" each |
| Bottom & top tooth thickness | 1/4" AR400 |
| Working length of teeth | 8 3/8" |
| 8 3/8" | 2" x 4" x 1 1/8" Rod |
| Maximum hydraulic pressure rating | 2500 psi |
