Features
| FEATURES | BENEFITS |
| Category 1 Three-point hitch or Pull-type Configurations. |
Matches customers operational and equipment needs. |
| Three point hitch model is Cat. 1 Quick Hitch compatible. |
Makes for faster and easier hook-up to the tractor. |
| Standard equipment support stands for both three-point hitch and pull-type models. |
Keeps the hitches up and out of the dirt and ready for easy hook-up. |
| Optional Pull-type Hitch assembly bolts on and converts the Three-point model to a Pull-type model. |
Provides low cost dual hitch capability for added value and operational versatility. |
| Indexing dual capability hitch on Pull-type configuration. |
Ensures easy fit and function for 2" ball or pin and clevis type attachment. |
| Low maintenance indexing flip-over hitch on pull-type configuration. |
Allows operator’s to switch from transport to working position and back again with ease and keeps costs down. |
| Notched and ribbed patterned gray iron roller. | Provides for optimal seedbed finish and long durable product life. |
Specs
| Hitch Type | Three-Point | Pull-Type |
| Unit Weight | 442 lbs. | 478 lbs. |
| Minimum Required Tractor Weight | 900 lbs. | 600 lbs. |
| Working Width | 69" | 69" |
| Overall Width | 77" | 84" |
| Overall Length | 18" | 77" |
| Overall Height | 30 3/4" | 18.9" |
| Roller Diameter | 11 3/8" | 11 3/8" |
| Roller Material Construction | Notched Gray Iron | Notched Gray Iron |
| Hitch Type | Cat. 1 and Cat. 1 QH Compatible | Pull-type Clevis and Indexing 2" Ball Combination |
| Tractor HP Requirement | 18-52 hp. | 18-52 hp. |
| Roller Scrapers | Standard Equipment | Standard Equipment |
| Transport Wheels | N/A | Two 10" x 3 1/4" Solid Rubber Straight Ribbed Tread |
| Hitch Support Stand | Standard Equipment | Standard Equipment |
