Features
| FEATURES | BENEFITS |
| Shorter yoke and boom tubing | Allows Post Hole Digger to be used on sub compact utility tractors (i.e. BX Kubota). |
| 2 7/8" Yoke | 3/16” Wall thickness for strength. |
| Auger length | 30” Auger. |
| Auger flighting | 1/4” Flighting, Semi-double flight. |
| Replaceable hardened steel points on auger |
Hardened points will last longer than non-hardened. Points can easily be replaced when worn or damaged. Cast steel auger fishtail tips. |
| Gearbox HP rating | 15 to 30 Horsepower. |
| 2" Output shaft | 2” tackles the torque loads that can be transmitted from hard ground. Fairly standard size for the industry, fits many competitive augers. |
| Large selection of augers | Variety of Dirt Auger sizes and styles to suit many applications. |
| Down pressure kit (optional) | Allows additional force to be supplied, hydraulically, to the beam to help force digger into the ground. |
| Alignment handle (optional) | Helps guide the auger from the tractor seat. |
| Post Hole Digger stand (optional) |
Bracket mounted to bottom of gearbox can incorporate a Post Hole digger stand . This allows operator to hook up and unhook from tractor more safely. Stand supports unit and will store unit when it is not on the tractor. |
Specs
| Model | PD10 |
| Tractor HP Range | 15 to 30 HP |
| Weight Without Auger | 120 lbs |
| Auger Length | 30" |
| Auger Flight Thickness | 1/4" |
| Auger Pipe | 2 1/2" ID |
| Auger Teeth | Forged, Individually Replaceable; 40 Degree angle installed on flat side; 50 Degree angle installed on angled side |
| Number of Teeth | 6" - 2 teeth; 9" & 12" - 4 teeth |
| Pilot | Cast Steel, 3 Drill points |
| Driveline | Cat. II Shearbolt |
| Maximum Operating PTO Speed | 300 RPM |
| Gearbox | 1 3/8" 6B spline input shaft, 3:1 Ratio |
| Gearbox Oil Capacity & Type | 3.4 Pints of SAE80-90W EP oil |
| Output Shaft | 2 O.D. Round |
| 3-Point Hitch Cat. | Cat. I |
| Boom | 2 7/8" O.D. |
| Yoke | 2 7/8" O.D. |
| Options and Accessories | |
| Auger Extensions (Accessory | 7" & 14" Extensions Available |
| Dirt Auger Sizes (Option) | 6", 9", or 12" |
| Bolt-on Rock Head (Accessory) | Not Available |
| Rock Auger Sizes (Option) | Not Available |
| Cat. III Torque Limiter Driveline | Not Available |
| Hydraulic Down Pressure Kit | Available |
| Storage Stand | Available |
