Adjustable handle bar
Adjustable and ergonomically designed handlebar for best comfort.
Powerful and Efficient X-TORQ® Engine
The X-Torq® engine design reduces harmful exhaust emissions by up to 60% and increases fuel efficiency by up to 20%.
Adjustable harness hook eyelet
Adjustable eye let for best balance
Trio-Balance harness
Ergonomic harness with broad back support, shoulder straps and hip belt that distributes the load over a larger area.
Quick Start with Air Purge
Air purge removes air from carburetor and fuel system for easy starting
Optimized center of gravity
Fuel tank placement in front of the engine improves balance.
Smart Start®
The engine and starter have been designed so the machine starts quickly with minimum effort. Resistance in the starter cord is reduced by up to 40%
Auto return stop switch
When the machine is turned off, the stop switch automatically returns to the start position for easier starting.
Ergonomic design
Angled handle bar and comfort grip handles improve operator posture.
Versatile guard
The cutting attachment guard can be used with either a grass blade or a trimmer head.
Easy cutting equipment conversion
Magnetic locking pin holder facilitates quick conversion of cutting equipment.
LowVib®
Effective anti-vibration dampeners absorb vibration, reducing stress on the user’s arms and hands.
Transparent fuel tank
Transparent fuel tank for checking the fuel level.
Optimal Cutting Performance
Trimmer head designed for high torque to deliver optimal cutting performance when parallel to the ground
High Line Capacity
Tap 'n' Go trimmer head is easy to use and refill
| Engine | 545FR SKU: 967 63 79‑05 |
| Cylinder displacement | 2.8 cu.inch |
| Power output | 2.8 hp |
| Fuel tank volume | 30.43 fl oz |
| Fuel consumption | 450 g/kWh |
| Idling speed | 2,700 rpm |
| Ignition module air gap | 0.01 in |
| Electrode gap | 0.02 in |
| Torque, max. | 2.6 Nm |
| Torque, max. at rpm | 6,000 rpm |
| Clutch engagement speed (±120) | 3,900 rpm |
| Maximum rpm output shaft | 8,800 rpm |
| Equipment | |
| Harness | Balance X |
| Saw blade | Scarlett 200-22 |
| Transmission | |
| Gear ratio | 1.4 |
| Lubricant | |
| Lubricant type (bevel gear) | Biodegradable grease |
| Sound and Noise | |
| Sound power level, guaranteed (LWA) | 117 dB(A) |
| Sound pressure level at operators ear | 100 dB(A) |
| Vibration | |
| Equivalent vibration level (ahv, eq) left handle | 3.6 m/s² |
