Belt eye let
Makes it quick and easy to connect the saw to the climbing harness.
Simple Starting
Stop switch automatically resets to ON so trimmer is ready for next use
Retained bar nut
The retaining function prevents loosing the bar nut.
Side Chain Tensioning
Quickly and easily adjust the chain
Quick release air filter cover
Quick release cover saves time when cleaning or changing air filter.
Easier cold starting
Starting a cold engine requires less effort thanks to the air purge.
Flip-up tank cap
The flip-up tank cap is easy to open.
Smart Start® Technology
Specially-designed engine and starter for easy and fast starting with minimum effort
| Engine | 12" SN 3/8 mini" 1,3 mm S93G SKU: 967 63 33‑12 |
| Chain speed at max power | 59.4 fts |
| Cylinder displacement | 1.65 cu.inch |
| Power output | 1.48 hp |
| Torque, max. | 1.28 Nm |
| Torque, max. at rpm | 6,000 rpm |
| Clutch engagement speed (±120) | 4,200 rpm |
| Electrode gap | 0.02 in |
| Idling speed | 2,900 rpm |
| Ignition module air gap | 0.02 in |
| Maximum power speed | 13,500 rpm |
| Oil pump type | Adjustable flow |
| Spark Plug | NGK CMR6A |
| Equipment | |
| Recommended bar length, min | 8 in |
| Pitch | 3/8" mini |
| Recommended bar length, max | 12 in |
| Chain type | S93G |
| Bar length | 30 cm |
| Bar length (inch) | 12 in |
| Sprocket type | Spur |
| Gauge | .050" |
| Dimensions | |
| Weight (excl. cutting equipment) | 5.95 lbs |
| Sound and noise | |
| Sound pressure level at operators ear | 98 dB(A) |
| Sound power level, guaranteed (LWA) | 111 dB(A) |
| Sound power level, measured | 110 dB(A) |
| Vibration | |
| Equivalent vibration level (ahv, eq) rear handle | 5.2 m/s² |
| Equivalent vibration level (ahv, eq) front handle | 4.9 m/s² |
| Lubricant | |
| Oil tank volume | 0.36 US pint |
| Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 |
