CTX50 Mini Skid Steer Features & Benefits

Packs a punch for its size

The vertical geometry lift loader arms help provide an ISO-rated operating capacity of 600 lb (272.2 kg).

Hydraulic pumps are directly attached to the engine, providing the machine with a significant power advantage compared to models that transfer power from the engine to the pump via a belt.

Quick and easy to maintain

Access to the engine and important components can be found near the upper and rear portion of the machine for easy maintenance.

The undercarriage features a high-mounted track sprocket. The higher mounting reduces premature wear and tear in rocky soil conditions, while the cast sprocket is heat-treated for longer life.

Operator centric design

The single, pilot-operated joystick offers the operator a smooth range of operation without balancing the engagement of two separate controls.

A dedicated spring-cushioned platform keeps the operator out of the mud. The integrated operator presence system suspends ground drive and powered boom/bucket motion when the operator steps off the platform.

CTX50 Mini Skid Steer Specs & Compare

GENERAL DIMENSIONS AND WEIGHTS
Design	Stand-on/Track drive
Length with Standard Bucket	95 in
Length without Standard Bucket	75 in
Width with Standard Bucket	42 in
Width Without Standard Bucket	35.5 in
Height	54.5 in
Height (to Hinge Pin)	72 in
Ground Clearance	6 in
Weight (Standard Bucket, Diesel Engine)	2245 lbs
Weight (No Bucket, Diesel Engine)	2100 lbs
ENGINE - OPTION ONE
Make and Model	Kohler Command PRO EFI ECH740
Fuel Type	Gasoline
Fuel Tank Capacity	4 gal
Gross Horsepower	25 hp
Cooling System	Air
Maximum Angle of Inclination	25 deg
TRACK PERFORMANCE
Rated Operating Capacity (SAE)	600 lbs
Ground Pressure (Narrow Tracks)	4.5 psi
Travel Speed	3.5 mph
OPERATIONAL
Steering	Single, pilot-opertated joystick
Lift	Single, dual axis
Curl	Single, dual axis
HYDRAULIC SYSTEM
Hydraulic Aux System Flow	12.5 gpm
Hydraulic System Pressure	2950 psi
Tank capacity	12 gal
