HG6000TX Horizontal Grinder Features & Benefits

Productive and powerful

The Series III duplex drum is built off the proven cutting performance of previous Vermeer duplex drum designs and makes maintenance more convenient with enhancements such as an independently secured wedge system and enhanced drum balancing.

Maximize feeding capability with machine sidewalls that provide optimal flow of material and minimize operator interaction.

The feed roller planetary is fully enclosed for protection from debris and offers a tighter clearance between the feed roller and mill housing, helping reduce material blockage and drag on the feed roller circuit.

The track-driven grinder offers onsite mobility with a remote control for easy maneuverability. The DT6 optional integrated dolly transport system eliminates the need for a dedicated trailer to move between sites.

Intelligent operation

Maximize productivity thanks to the exclusive Vermeer SmartGrind system, which automatically controls grinding speed based on engine rpm levels.

Machine damage caused by metal contaminants entering the hammermill can be costly. The Vermeer Damage Defense system helps protect your machine by detecting certain metal contaminants.

An industry-leading, full-function, wireless remote control lets you adjust machine settings from the cab as conditions change, including control of the infeed settings, engine droop, conveyor height and more.

Ease of maintenance

Top-loading screens are designed to give operators easy access.

Safety

Reduce the quantity and distance of thrown material debris with the Thrown Object Deflector (TOD), strategically placed to reduce interference when loading over-length material.

Your access to MORE: VermeerOne™

VermeerOne™ Platform isn’t just a tool or platform. It’s an experience — one designed to simplify equipment management, empower users with real time data to make smarter decisions, and help maximize productivity and profitability.

HG6000TX Horizontal Grinder Specs & Compare

GENERAL DIMENSIONS AND LENGTHS - LONG INFEED
Maximum Length - Transport37.3 ft
Maximum Length - Transport with Dolly45.8 ft
Maximum Length (Operation)54.5 ft
Maximum Width Transport - with Dolly9.8 ft
Maximum Height Transport with Dolly154.8 in
Weight75000 lbs
Tongue Weight - Engine Option 1 with Dolly37590 lbs
Axle Weight - Engine Option 1 with Dolly48910 lbs
Dolly Weight9500 lbs
ENGINE - OPTION ONE
Make and ModelCaterpillar C18 Tier 4F (Stage IVB)
Number of Cylinders6
Gross Horsepower (Maximum)755 hp
Torque (Max)2582 ft-lb
Fuel Tank Capacity350 gal
Max Fuel Consumption38.3 gph
Fuel TypeUltra-low sulfur diesel (<15 ppm)
Air CleanerDry-type with primary and secondary elements and restriction indicator
Oil FilterFull-flow, spin-on
Recommended OilAPI CJ-4, 15W-40
Oil Volume with Filter36 qt
Cooling MediumLiquid
Coolant Capacity (Engine and Radiator)22.6 gal
Alternator24 Volt
Fan(Qty 2) Hydraulically driven, reversible
Fan - CACHydraulic (variable speed)
Clutch TypeHydraulic-operated wet clutch with PTO
Clutch EngagementPush-button
Drive Belt TypeSynchronous, carbon fiber
ENGINE - OPTION TWO
Make and ModelCaterpillar C18 Tier 4i (Stage IIIB)
Number of Cylinders6
Gross Horsepower (Maximum)755 hp
Torque (Max)2582 ft-lb
Fuel Tank Capacity350 gal
Max Fuel Consumption39.5 gph
Fuel TypeUltra-low sulfur diesel (<15 ppm)
Air CleanerDry-type with primary and secondary elements and restriction indicator
Oil FilterFull-flow, spin-on
Recommended OilAPI CJ-4, 15W-40
Oil Volume with Filter36 qt
Cooling MediumLiquid
Coolant Capacity (Engine and Radiator)22.6 gal
Air to Boil Temperatur118 deg
Alternator24 Volt
Fan(Qty 2) Hydraulically driven, reversible
Clutch TypeHydraulic-operated wet clutch with PTO
Clutch EngagementPush-button
Drive Belt TypeSynchronous, carbon fiber
Sound Power119.8 dB(A) - deluxe exhaust system (Exhaust option 2 move to engine option one
ENGINE - OPTION THREE
Make and ModelCaterpillar C18 Tier 3
Number of Cylinders6
Gross Horsepower (Maximum)630 hp
Torque (Max)2041 ft-lb
Fuel Tank Capacity350 gal
Max Fuel Consumption34.6 gph
Fuel TypeDiesel
Air CleanerDry-type with primary and secondary elements and restriction indicator
Oil FilterFull-flow, spin-on
Recommended OilAPI CJ-4, Viscosity dependent on startup temperature
Oil Volume with Filter36 qt
Cooling MediumLiquid
Coolant Capacity (Engine and Radiator)21.3 gal
Alternator24 Volt
Fan(Qty 2) Hydraulically driven, reversible
Clutch TypeHydraulic operated wet clutch with PTO
Clutch EngagementPush-button
Drive Belt TypeSynchronous, carbon fiber
Sound Power119.8 dB(A) - Deluxe exhaust system
STANDARD INFEED SYSTEM
Feed opening32-in (81.3-cm) high x 56.4-in (143.3-cm) wide
Infeed roller weight with arm3350 lbs
HEAVY-DUTY INFEED SYSTEM
Feed opening32-in (81.3-cm) high x 56.4-in (143.3-cm) wide
Infeed roller weight with arm3483 lbs
SAFETY SYSTEM
Thrown Object DeflectorStandard
Deflector PositionVariable
DUPLEX DRUM
Millbox Opening60" W x 32" H (152.4 cm W x 81.3 cm H)
Drum Weight4741 lbs
Drum Diameter28 in
Tip Diameter36.4 in
Drum Cutting Width62.4 in
Drum Skin Thickness1.5 in
Drum Speed1086 rpm
Bearing TypeDouble row, spherical roller
Bearing - Inner Race Diameter5.5 in
Number of Hammers10
Number of Tips20
Tip typesPremium wide
Center Retention Pin Dimensions2" diameter x 75.3" L (5.1 cm diameter x 191.3 cm L)
CHIPPER DRUM
Millbox Opening60
Drum Weight5946 lbs
Drum Diameter34.3 in
Drum Cutting Width63 in
Drum Skin Thickness1.5 in
Depth of CutAdjustable: .125 in (.31 cm) to 1 in (2.5 cm)
Number of Knives28
Knife Thickness.625 in (1.6 cm)
Useable Edges1
MaterialA8 mod chipper steel
Number of Bolts/Knife2
Replaceable Threaded Knife BlockYes
Number of Pockets14
Drum Speed683 rpm
Bearing TypeSpherical
Bearing - Inner Race Diameter5.5 in
Shaft diameter6.5 in
Shaft Retention TypeKeyless bushing
SCREENS
Screen Weight470 lbs
Screen Dimensions3/4" (1.9 cm) thick
Screen TypeFabricated out of abrasion resistant steel
Number of Screens2
Screen Area3317 sq in
Millbox lid linerAbrasion-resistant steel
Number of Sides1
Millbox Lid Liner DimensionsAbrasion resistant steel
Liner Dimensions1" thick x 5.6" W x 65.4" L (2.5 cm thick x 14.2 cm W x 166.1 cm L)
Anvil TypeFabricated steel with replaceable wear surfaces
Anvil Dimensions22.8"x 4.1"x 80.8" (57.9 cm x 10.4 cm x 205.2 cm)
DISCHARGE SYSTEM - SINGLE BELT DESIGN
Length81.3 ft
Width48 in
Belt Design3 ply - 330# or straight warp single ply 330# both with V cleat
SpliceR2-stainless steel or Super splice
Return Roller Quantity4
Idler Roller Diameter12 in
Idler Roller Bearing1-15/16, 4-bolt flange
Standard Drive Roller Diameter12.8 in
Magnetic Drive Roller Diameter12.8 in
Drive MotorFixed displacement, geroler
Drive Motor Bearings1-15/16, 4-bolt flange
Belt Speed780 ft/min
Load Height14 ft
HYDRAULIC SYSTEM
Tank capacity100 gal
Recommended OilVermeer HyPower 68
Filtration MethodDual in-tank return filters with suction strainer
Number of Coolers2 (Implement/Track)
IMPLEMENT HYDRAULICS
System TypeOpen-loop, pressure- and flow-compensated
Pump TypeVariable displacement, axial piston
Pump Flow at Maximum RPM32.4
System Relief Pressure4500 psi
DISCHARGE CONVEYOR HYDRAULICS
System TypeOpen-loop
Pump TypeFixed displacement, gear pump
Pump Flow at Maximum RPM25.7 gpm
System Relief Pressure3000
Motor SeriesChar-Lyn 6000 Series, geroler
FAN DRIVE HYDRAULICS
System TypeOpen-loop, pressure- and flow-compensated
Pump TypeVariable displacement, axial piston
Pump Flow at Maximum RPM36.2 gpm
Motor SeriesRadiator-Permco M197 Series; CAC-Turolla OCG SNM2 Series
Fan Series - FWD/REVReversible
CLUTCH
Tank capacity18 gal
Recommended OilVMF Gold
Filtration MethodSpin-on, pressure filter, B6 = 1000
Number of Coolers1
System TypeOpen-loop
Pump TypeFixed displacement, gear pump
Pump Flow at Maximum RPM12.4 gpm
System relief pressure260 psi
ELECTRICAL SYSTEM
System Voltage24 Volt
BatteryGroup 8-D, 1155 CCA (Qty 2)
System ProtectionFused
CONTROL STATION
Display TypeLCD
Engine InformationYes
Machine InformationYes
Operational FaultsYes
GaugesTwo, fuel level and hydraulic pressure
SwitchesMoisture-proof, toggle style
RADIO REMOTE CONTROL
Radio remote typeR524
Display TypeLCD
Engine InformationYes
Machine InformationYes
Operational FaultsYes
SwitchesSealed membrane
Operating RangeUp to 300' (91.4 m)
Battery TypeAA (qty 6)
Channel Setting50 channels
CHASSIS
Frame DescriptionUnit body construction
Tongue DescriptionBolt-on to infeed structure
Hitch TypeFifth wheel
Fender DescriptionOptional bolt-on formed steel
Brake TypeAir-actuated with spring-applied parking brake
Trailer Light Type12-24 V LED
AXLE/SUSPENSION
Suspension TypeAir-ride
Manufacturer - Option OneHendrickson
Capacity per Axle20000 lbs
Number of Axles3
Tires - Option One255/70R22.5 Duals
Wheels - Option One22.5"x 8.3" (57.2 cm x 21 cm) Hub piloted steel
Ground Clearance - Option One5.3 in
TRACKS
Track Frame DescriptionRigid frame with reinforced box section.
Track TypeD5 double grouser
Track Drive Pump TypeSauerDanfoss Series H1
Track Brake TypeMultidisk parking brake (spring activated)
Track Length on Ground142" (360.7 cm)
Track Width - Option One26" (66 cm)
Track Width Option One - Ground Bearing Pressure - Hard Ground55.6 psi
Track Width Option One - Ground Bearing Pressure - Soft Ground10.2 psi
Track Width Option Two - Ground Bearing Pressure - Option13.2 psi
Track Width Option Two - Ground Bearing Pressure - Option Two72.2 psi
Type of IdlerD5 excavator rollers
Number of Idlers20
Pump Flow at Maximum RPM43 gpm
System relief pressure5000 psi
Maximum Speed2.6 mph
Low Speed Travel in Creep Mode1 mph
OPTIONAL AIR COMPRESSOR
Air Compressor BrandMi-T-M
EngineHonda, 11.7 hp (8.7 kW)
Maximum Pressure175 psi
Maximum Air Flow29 cfm
Tank capacity (5th wheel)30 gal
OTHER OPTIONS
ScreensYes
TipsYes
Special Tools GroupYes
Magnetic discharge conveyor pulleyYes
Extended WarrantyYes
Preventative MaintenanceOptional
Special PaintYes
Air CompressorOptional
Vermeer Confidence Plus Asset Protection ProgramOptional
