BC700XL Brush Chipper Features & Benefits

Transport with ease

Easily move from jobsite to jobsite with the smallest member of the Vermeer brush chipper line.

Intelligent feeding

A large infeed opening simplifies feeding irregular material and reduces the need for crosscuts before feeding the chipper.

SmartFeed, a patented feed-sensing control system, boosts operator productivity and reduces engine strain by monitoring engine rpm and controlling feed rollers.

Safety

The patented bottom feed stop bar is strategically positioned so the operator can strike it to shut off the feed mechanism in an emergency.

Your access to MORE: VermeerOne™

VermeerOne™ Platform isn’t just a tool or platform. It’s an experience — one designed to simplify equipment management, empower users with real time data to make smarter decisions, and help maximize productivity and profitability.

BC700XL Brush Chipper Specs & Compare

GENERAL DIMENSIONS AND WEIGHTS
Length - Feed Table Up, Tongue In115 in
Length - Table Down, Tongue Extended136 in
Width71 in
Height102 in
Weight - Engine Option One1800 lbs
Tongue Weight - Engine Option One180 lbs
ENGINE - OPTION ONE
Make and ModelKohler ECH740
Gross Horsepower (Maximum)25 hp
Torque (Max)41.7 ft-lb
Fuel Tank Capacity6 gal
Max Fuel Consumption2.4 gph
Fuel TypeGasoline
Air CleanerKohler HD 2-Stage Dry
Oil FilterSpin-on
Recommended OilKohler oil or API CH4/SJ
Oil Volume with Filter2 qt
Maximum Angle of Continuous Operation25 deg
Cooling MediumOil/Air
Alternator20A Charging
Clutch TypeCentrifugal PTO
Clutch Drive EngagementCentrifugal
FEED SYSTEM
Feed Roller OrientationHorizontal
Feed Roller Clamp Load525 lbs
Feed Roller Clamp TypeSpring/Feed Roller Weight
Feed Roller Minimum Distance to Drum4 in
Feed Roller Dimension10" Diameter
Weight of Feed Roller100 lbs
Motor Displacement14
Motor ManufacturerWhite Hydraulics
Feed Speed49.4 ft/min
Infeed Table Width41.2 in
Infeed Table Length30.2 in
Infeed Hopper Height22.1 in
Infeed Throat Capacity6" x 8" (15.24 cm x 20.32 cm)
Pinch Point - Distance to End of Feed Table65.4 in
Distance from Feed Table to Ground28.1 in
SAFETY SYSTEM
Bottom Feed Stop BarStandard
Bottom Feed Stop Bar Diameter2 in
Bottom Feed Stop Bar Material Thickness12" (30.48 cm)
Reset MethodDual green hold-to-run buttons
Four Position Feed Control BarStandard
Diameter2 in
Material Thickness.1 in
PositionsFour position: (E-Stop), Forward, Stop, (Reverse)
Green Hold to Run ButtonStandard
DRUM/DISC CUTTING SYSTEM
Material Capacity6 in
Width8 in
Thickness1.3 in
Diameter23.9 in
Speed1748
Weight With Shaft176 lbs
Knife Thickness.6 in
MaterialA8 Chipper Steel
Replaceable Threaded Knife BlockYes
Fixture MethodWelded
Air Flow5000 cfm
Bedknife Size4" x 8.6"/(10.2 cm x 21.9 cm) hor; 4" x 5.8"/(10.2 cm x 14.6 cm) vert
Bedknife MaterialASTM A572 Grade 50
CUTTER DRIVE COMPONENTS - ENGINE OPTION ONE
Bore1.5 in
TypeFlange-mounted ball type, self-aligning
ManufacturerLinkbelt
Dynamic Capacity5640 lbs
Static Capacity4460 lbs
Belt Idler/TensionerSpring-loaded adjustable Idler
Belt Type2-band 5-V profile Aramid
DISCHARGE SYSTEM
Chute Height97.2 in
Bottom Thickness.1 in
Top Thickness.1 in
Side Wall Thickness.1 in
Deflector Thickness.1 in
Chute Rotation Angle240 deg
Rotation TypeManual
Rotational LockStandard Latch
HYDRAULIC SYSTEM
Tank capacity6.8 gal
Recommended Oil TypeVermeer VMF Gold
System TypeOpen center
Filtration MethodReturn flow filtration, 10 micron
Pump Flow at Maximum RPM3.8 gpm
System relief pressure2500 psi
ELECTRICAL SYSTEM
System Voltage12 Volt
BatteryGroup 26, 400 CCA
Standard GaugesHour meter
SwitchesHold-to-run, sensitivity selector
ControllerVermeer ACS CB02
CHASSIS
Frame Description3/16"/(.5 cm) ASTM A1011 steel
Hitch Type2"/(5.1 cm) ball coupler
Fender Description.1"/(.3 cm) Steel bolt-on
Axle/Suspension2000 lb/(907.2 kg) rubber torsion axle
Type - Option OneRubber Torsional
Manufacturer - Option OneDexter
Capacity - Option One2000 lb/(907.2 kg)
Tires - Option OneST185/80D13 load range D
Wheels - Option One13 x 5, bolt circle 5 on 4.5
Axle/Suspension - Option Two2000lb/(907.2 kg) rubber torsion axle with electric brakes
Type - Option TwoRubber torsional, braked
Manufacturer - Option TwoDexter
Capacity - Option Two2000 lb/(907.2 kg)
Brake TypeElectric optional
Trailer Light TypeLED
OTHER OPTIONS
Special PaintAvailable, Optional
Extended WarrantyAvailable, Optional
Preventive MaintenanceAvailable, Optional
