Take the effort out of adjusting cut height. Easily lift the deck in quarter-inch increments from 1.5" to 5.0"
Our iCD Cutting System has an extra wide opening to disperse clippings quickly and evenly, while our sloped nose design allows you to cut at higher speeds without sacrificing quality of cut.
Greasable, cast-aluminum spindles provide a longer life for your mower. Hydro-Gear ZT-3200™ Drive System is designed for high performance and is fully serviceable.
Powerful engines, commercial grade transaxles and larger cutting decks deliver the perfect combination for a commercial fleet.
Quick removal of the floor pan provides convenient access to the top of the deck for easy cleaning and service.
Model Number | 5901867 |
Engine Brand | Briggs & Stratton® Commercial Series |
Engine Power Rating (hp)* | 25 |
Engine Displacement (cc) | 724 |
Number of Cylinders | 2 |
Fuel Tank Capacity (gal) | 5.5 |
Transaxles | Hydro-Gear® ZT-3200™ w/ 7" Cooling Fans |
Drive Axles | 1.125 |
Drive Tires (in) | 22 x 11-10 |
Caster Tires (in) | 13 x 6.5-6 Pneumatic |
Cutting Width (in) | 52 |
Cutting Height (in) | 1.5 - 5 |
Deck Construction | iCD™ Cutting System |
Greasable Spindles | Cast-aluminum |
Ground Speed-Fwd (mph) | 0-10 |
Ground Speed-Rev (mph) | 0-5 |
Seat Package | Mid-back with armrests |
Roll Over Protection System with retractable seatbelt | 180° Foldable |
Instrumentation | Hour meter, Fuel level gauge |
Safety Group / Controls | Seat Actuated Engine Kill, Blade, Clutch Safety Switch, Neutral and Parking Brake Safety Circuit, Adjustable Twin Steering Controls |
Parking Brake | Internal Transaxle |
Overall Length (in) | 80 |
Overall Width (in) deflector down / deflector up (model) | 67.5/54.5 |
Dry Weight (lbs) | 1059 |
*All power levels are stated gross horsepower at 3600 RPM per SAE J1940 as rated by Briggs & Stratton. |
