Our patented control system provides a natural, ergonomic hand position for improved comfort.
Easily adjust the mower's speed with one hand during operation.
Optional one-wheel or two-wheel accessory that allows operators to ride behind the unit.
Hydro-Gear® ZT-3400® transaxle with dual external oil coolers and steel cut gears for improved reliability and power.
Model Number | 5901902 |
Engine Brand | Kawasaki FX651V |
HP (gross) * | 20.5 |
Displacement (cc) | 726 |
Number of Cylinders | 2 |
Fuel Tank Capacity (gal) | 5 |
Transmission | Hydro-Gear® ZT-3400® with dual external oil coolers, steel cut gears and 1.25" shafts |
Ground Speed-Fwd (mph) | 0-7 |
Ground Speed-Rev (mph) | 0-3 |
Cutting Width (in) | 48 |
Height-of-Cut (in) | 1.5 - 5 |
Deck Construction | 10-gauge, fabricated |
Spindles | Cast-iron |
Drive Axles | 1 |
Drive Tires (in) | 20 x 7-10c |
Caster Tires (in) | 11 x 4-5 |
Overall Length (in) | CC: 75' |
Overall Width (in.) deflector down / deflector up (model) | 62.5 / 49.5 |
Dry Weight (lbs) | 809 |
Instrumentation | Dual-function hour meter, speed indicator |
Controls/Safety Group | Operator presence, centralized foot activated neutral pedals, neutral start safety circuit/CC™ (Centralized Controls) or standard controls |
Parking Brake/Safety Circuit | Hand operated internal transaxle |
*All power levels are stated gross horsepower per SAE J2723 as rated by Kawasaki. |
