Neutral Positioned Centrally
Centralized foot control for neutral position provides the operator with a more natural control. The neutral position is identified on the speed indicator on the dash.
Protects and Delivers
Heavy-duty transmission guards reduce build up of debris to improve air flow and allow for access to the filter for maintenance.
Easy Reach Brake
Brake handle is conveniently located beside the control panel. Lever requires minimal operator effort to engage.
Improved Deck Mounting
The mower deck mounting system provides easier deck leveling, improved flexibility over terrain and more durable wear points for reduced maintenance.
CC™ Centralized Controls
The design of the CC™ Centralized Controls places the operator's hands in the ideal position to access all in-demand controls. Ergonomic operator presence, steering and reverse levers on both handles operate with a light touch to reduce operator fatigue (Select Models).
Set Your Speed
Reliably set your speed with the improved easy-to-reach cruise control bar featuring a convenient speed indicator.
No Need to Restart
Need to walk away from the mower to move an obstacle or debris? The new PTO switch allows the operator to stop the mower blades in a single step – simply put the machine in neutral and release the controls. The blades will disengage while the engine continues to run.
Longer Belt Life
Deck drive belt system is designed to provide even belt tension which improves the life of the belt and reduces maintenance.
Easily Secure Equipment
Dedicated tie-down points, located in front and rear, make securing equipment convenient.
Drive System
Independent, commercial Hydro-Gear® ZT-3100® cooling fans that assist with repelling debris. Designed for high performance and fully serviceable.
Engine Brand | Kawasaki® FS600V |
HP (gross) * | 18.5 |
Displacement (cc) | 603 |
Number of Cylinders | 2 |
Fuel Tank Capacity (gal) | 5 |
Transmission | Commercial Hydro-Gear® ZT-3100® transaxles with 7" mounted cooling fans® |
Ground Speed-Fwd (mph) | 0-6 |
Ground Speed-Rev (mph) | 0-3 |
Cutting Width (in) | 48 |
Height-of-Cut (in) | 1.5 - 4.5 |
Deck Construction | 10-gauge, fabricated |
PTO | Electric |
Spindles | Cast-aluminum, greaseable |
Frame Rail | 1.5" x 2", 11-gauge |
Finish | Powdura® super durable power coat, a high gloss powder coat with excellent impact resistance and outstanding salt and U.V. protection |
Drive Axles | 1 Tapered |
Drive Tires (in) | 20 x 7-10 |
Caster Tires (in) | 9 x 3.5-4 Flat-Free |
Overall Length (in) | 78 |
Overall Width (in.) deflector down / deflector up (model) | 59.75 / 52.25 |
Dry Weight (lbs) | 694 |
Instrumentation | Hour meter, speed indicator |
Controls/Safety Group | Operator presence, centralized foot activated neutral pedals, neutral start safety circuit / CC™ (Centralized Controls) |
Parking Brake/Safety Circuit | Internal Transaxle |
