Rhino TR308
Innovative new suspension and driveline designs.
The robust TR Series is the latest addition to RhinoAg’s already-impressive lineup of multi-spindle cutters. These rugged cutters offer superior cut quality, easier maintenance, and longer life expectancy to give you the years of dependable service you’ve come to expect from RhinoAg.
The 300 pull types feature a rigid-deck suspension system that creates a more even cut and offers longer part life due to reduced impact load on critical components. As heavier units, the TR308 and TR310 need this independent axle suspension to help reduce the hard, continuous impacts that cutters see out in the field daily.
Shopping Tools
TR308 Features & Benefits
- Clean, modernized deck design for easy cleaning and maintenance
- CV drivelines on all pull-type units
- CAT 2 & 3 hitch compatible
- Slip clutch driveline protection
- EZ cutting boxes on every unit; EZ160 divider box and EZ160 cutting box on the TR310
TR308 Specs & Compare
| Model | TR308 |
| Cutting Width | 8' (96'') |
| Overall Width | 103'' |
| Overall Length | 94 1/2'' - Lift |
| 97 1/2'' - Semi | |
| 143'' - Pull | |
| Cutting Height | 1'' - 15'' |
| Height Adjustment | Cylinder - Pull/Semi |
| Jack Stand | Std. - Pull |
| Hitch | CAT 2/ CAT 3 Std. |
| CAT 2/ CAT 3 Q.H., Pull | |
| Blade Carrier | Infinity - Steel |
| Blades | 1/2'' x 4'' Parallel |
| Blade OverLap | 4'' |
| HP Required | 55 HP - Lift |
| 35 HP - Pull/Semi | |
| Gearbox Rating* - Center | 100 HP |
| Gearbox Rating* - Outboard | 130 HP |
| Gearbox Oil (85W-140) | Factory Filled Lucas Oil |
| Output Shaft Diameter | 2" (50 mm) |
| Blade Tip Speed - 540 RPM | 16,512 FPM |
| Blade Tip Speed - 1000 RPM | 16,378 FPM |
| Cutting Capacity (Max) | 3'' |
| Driveline Size | CAT 4 - Lift/Semi |
| CAT 5 - Pull | |
| Driveline Protection | Slip Clutch |
| Deck Thickness | 10 Ga |
| Side Skirt | 1/4'' |
| Tires & Wheels | Laminate - Lift |
| Laminate or HD Rhino Trax - Pull | |
| Safety Tow Chain | Std. - Pull |
| Safety Deflector | Single or Double Chain Guards |
| Tongue Weight | 1,020 lbs |
| Weight | 1,950 lbs (Lift), 2,350 lbs (Pull) |
| * Gearbox power ratings based on actual field performance | |
