Get a professional finish year-round.

The pristine cut offered by the RhinoAg X Series Roller Mowers is now more accessible than ever. Smaller cutting widths make the X603 and X804 ideal for more compact applications that still need the professional finish the X Series is known for.

With a versatile cutting height up to 5”, these rigid-deck roller mowers get the job done without fuss. The tempered steel blades pivot on high-tensile pivot bush assembly and there are no belts, making maintenance simple.

  • Get a Quote Value Your Trade Request Brochure
  • Send to a Friend
  • Payment Calculator

    • Get information on the X603

    Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.

    Request Brochure

    Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.

    Send your friend information on the X603

    Fields with asterisks* are required. Your friend will receive an email that contains a reference to this page. Please send this email only to people you know who would be interested in this information.

    Requesting Trade In on X603

    Contact Information
    Equipment Interested In
    Trade Information

    Request A Demo

    Fields with asterisks* are required.

    Loan Calculator

    Use the Loan Calculator to help you determine the financing and payment options that are best for you.

    Amount Financed ($)
    Interest Rate (%)
    Loan Term in Months
    Monthly Payment Calculated

    **The accuracy of this calculator and its applicability to your circumstances is not guaranteed. You should obtain personal advice from qualified professionals. This information is provided for illustrative purposes only and does not constitute an application. This notice does not guarantee loan approval, nor is it an offer or commitment to make a loan to you on the above terms.

Shopping Tools
Contact Salesman
Request Demo
Apply for Financing

X603 Features & Benefits

  • 100% gear driven - no belts
  • Reinforced 8-gauge Strenx® 700 MC structural steel deck
  • Hardened, tempered spring steel blade carrier
  • 3” x ¼” hardened, tempered, ground-edged parallel spring steel blades with 2 ½” overlap
  • Sealed internal roller bearings for total protection against moisture, soil, and debris
  • Galvanized finish for durability
  • PTO Requirement of 50 - 60 HP

X603 Specs & Compare

MODELX603
Cutting Width6' 3"
Transport Width6' 6"
Overall Length4' 3"
Cutting HeightUp to 5"
HitchLift-Type
Blade Carrier3 1/4" x 3/8" spring steel, hardened and tempered
No. of Blades6
Blades3" x 1/4" spring steel ground edged parallel hardened and tempered,
pivoting on high tensile pivot bush assembly
Rotars3
Mowing Rates5.3 acres/hr @7mph
Blade Overlap2 1/2"
PTO Horsepower Required (Min)50 HP
Tractor PTO540 RPM
Output Shaft Diameter1 1/2" (40mm)
Gearbox Oil85W-140 Factory Filled
Blade Tip Speed14,764 FPM
DrivelinesCAT 4 - 1 3/8" 6-spline
Deck Thickness8 Guage Strenx® 700MC folded monocoque construction with
reinforcement and underside trough is 8 guage Strenx® 700MC
Weight1,047 lbs
