Flexible, Efficient, & Economical

  • Moves feed, granular materials, bulky fibrous materials, sawdust, and more
  • Conveys high volumes of materials up inclines (up to 40°) with low HP requirements
  • Overall lengths range from 4' to 100'
  • Trough widths range from 10" - 16"
  • Use when material is moving through differing temperatures, or inside to outside
  • Detachable steel chain with steel or rubber flites (based on unit selection)
  • Get a Quote Value Your Trade Request Brochure
  • Send to a Friend
  • Payment Calculator

    • Get information on the Chain & Flite Conveyors

    Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.

    Request Brochure

    Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.

    Send your friend information on the Chain & Flite Conveyors

    Fields with asterisks* are required. Your friend will receive an email that contains a reference to this page. Please send this email only to people you know who would be interested in this information.

    Requesting Trade In on Chain & Flite Conveyors

    Contact Information
    Equipment Interested In
    Trade Information

    Request A Demo

    Fields with asterisks* are required.

    Loan Calculator

    Use the Loan Calculator to help you determine the financing and payment options that are best for you.

    Amount Financed ($)
    Interest Rate (%)
    Loan Term in Months
    Monthly Payment Calculated

    **The accuracy of this calculator and its applicability to your circumstances is not guaranteed. You should obtain personal advice from qualified professionals. This information is provided for illustrative purposes only and does not constitute an application. This notice does not guarantee loan approval, nor is it an offer or commitment to make a loan to you on the above terms.

Shopping Tools
Contact Salesman
Request Demo
Apply for Financing

Chain & Flite Conveyors Features & Benefits

Standard Features & Options


DETACHABLE STEEL CHAIN
Detachable steel chain for easy servicing.

DOUBLE HOOK LINKS
Heat-treated, heavy-duty, double-hook links are welded to 2″ x 15-1/2″ steel flites.  Flite spacing is 14-1/2″.  Links are detachable without tools for easy servicing.

INSTALLATION VERSATILITY
Motor can be mounted on top or bottom, left or right side.

DECLINE ELBOW
Decline elbow increases flexibility and permits elevation change without additional motors.

COVERS
Covers (optional) can protect your conveyor and materials from rain, wind, and contaminants.

VARIABLE FREQUENCY DRIVE
Adjust and control motor speed.  Available in 230V, 3 phase. 1 phase also available.

Chain & Flite Conveyors Specs & Compare

Chain & Flite Conveyor1025C1040C1630C
Trough Width10″ (254mm)10″ (254mm)16″ (406mm)
Chain Speed160 FPM98 FPM75 FPM
Overall Length11′ - 26′ (3.5 - 8m)11′ - 66′ (3.5 - 20m)11′ - 100′ (3.5 - 30.5m)
Full Load Capacity1,460 lb/min810 lb/min1,190 lb/min
Support Span< 25′ (7.6m)< 40′ (12.0m)< 30′ (9.1m)
