Economical, low maintenance, simple installation

  • Belt widths range from 12" - 36"
  • Overall belt lengths range from 4' - 205'
  • Layout flexibility - customize to fit your needs
  • Durable - conveyor sections are made of heavy-gauge steel and powder coated
  • Move material with adjustable decline, incline, or straight-line one-way conveying; reverse available in straight-line conveyor
  • Ideal for light-to-medium materials, such as feed, grain, sawdust, forage, mulch
  • Get a Quote Value Your Trade Request Brochure
  • Send to a Friend
  • Payment Calculator

    • Get information on the Belt Conveyors

    Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.

    Request Brochure

    Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.

    Send your friend information on the Belt Conveyors

    Fields with asterisks* are required. Your friend will receive an email that contains a reference to this page. Please send this email only to people you know who would be interested in this information.

    Requesting Trade In on Belt Conveyors

    Contact Information
    Equipment Interested In
    Trade Information

    Request A Demo

    Fields with asterisks* are required.

    Loan Calculator

    Use the Loan Calculator to help you determine the financing and payment options that are best for you.

    Amount Financed ($)
    Interest Rate (%)
    Loan Term in Months
    Monthly Payment Calculated

    **The accuracy of this calculator and its applicability to your circumstances is not guaranteed. You should obtain personal advice from qualified professionals. This information is provided for illustrative purposes only and does not constitute an application. This notice does not guarantee loan approval, nor is it an offer or commitment to make a loan to you on the above terms.

Shopping Tools
Contact Salesman
Request Demo
Apply for Financing

Belt Conveyors Features & Benefits

Standard Features & Options


RETURN WHEELS / RETURN ROLLERS
Return wheels or return rollers carry belt on return bottom reducing friction and providing a longer belt life.  It also puts less strain on the drive system.

OPEN PAN DESIGN
Open pan design provides for extra capacity and reduces belt friction for lower power requirements.  Fin pulley helps reduce material build-up for better belt tracking.

PRECISION BEARINGS
Precision bearings are sealed and greasable, ensuring long-life and trouble-free, continuous duty.

BELT TENSION ADJUSTMENT & TRACKING
Conveniently adjust belt tension and tracking.  A 5/8″ screw provides up to 20″ of belt take-up.  The pulley is finned for clean-out.

DECLINE / INCLINE ELBOWS
Elbows increase flexibility and permits elevation change without additional motors.

COVERS
Covers (optional) can help protect your conveyor and materials from rain, wind, and contaminants.

DRIVES
Drive Pulley, the standard drive, is crowned, steel and rubber lagged.   Other drive options include:  Electric and hydraulic.

Belt Conveyors Specs & Compare

Belt Conveyor120516051608240524103605
Direction1-way2-way1-way2-way2-way1-way
Belt Width12″ (305mm)16″ (406mm)16″ (406mm)24″ (610mm)24″ (610mm)36″ (914mm)
Belt Speed65-370 FPM65-370 FPM260-390 FPM65-370 FPM95-325 FPM65-370 FPM
Overall Length10′ - 160′ (3.05 - 48.77m)10′ - 120′ (3.05 - 36.58m)10′ - 200′ (3.05 - 60.96m)10′ - 120′ (3.05 - 36.58m)10′ - 400′ (3.05 - 120.92m)10′ - 120′ (3.05 - 36.58m)
Full Load Capacity3,700 lb/min3,700 lb/min3,900 lb/min3,700 lb/min3,250 lb/min3,700 lb/min
