Reduce field trips and save money with the Landoll 877 Tilloll. Level, incorporate, and bring soil to a nearly perfect planting condition in one pass.

  • Get a Quote Value Your Trade Request Brochure
  • Send to a Friend
  • Payment Calculator

    • Get information on the 877-15

    Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.

    Request Brochure

    Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.

    Send your friend information on the 877-15

    Fields with asterisks* are required. Your friend will receive an email that contains a reference to this page. Please send this email only to people you know who would be interested in this information.

    Requesting Trade In on 877-15

    Contact Information
    Equipment Interested In
    Trade Information

    Request A Demo

    Fields with asterisks* are required.

    Loan Calculator

    Use the Loan Calculator to help you determine the financing and payment options that are best for you.

    Amount Financed ($)
    Interest Rate (%)
    Loan Term in Months
    Monthly Payment Calculated

    **The accuracy of this calculator and its applicability to your circumstances is not guaranteed. You should obtain personal advice from qualified professionals. This information is provided for illustrative purposes only and does not constitute an application. This notice does not guarantee loan approval, nor is it an offer or commitment to make a loan to you on the above terms.

Shopping Tools
Contact Salesman
Request Demo
Apply for Financing

877-15 Features & Benefits

  • 20” Concave Disc Blades Spaced at 7 ½”
  • 10 Degree Gang Angle
  • Reversible Scrapers
  • C-Cushion Bearing Standards with 1 ½” Gang Bolt
  • Soil Deflector/Spray Shield on Disc Gangs
  • Spring Clamp Shanks with 170 lbs. of Point Load
  • 25 ½” Under Frame Clearance
  • 9” Shank Spacing
  • 10” Sweeps
  • Chopper Reel and Spike Leveling Attachment
  • 16” 5-Blade Reel Mounted on Trunnion Bearings and C-Cushion Bearing Standards
  • Chopper Mounted at 10 Degree Angle to Return Dirt from Front Gangs
  • 3-Bar Spike Drag with Adjustable Spring Down Pressure and Tooth Angle
  • Single Lip Cat. III or Cat. IV Hitch, Model Dependent
  • Walking Tandem Wheels, Heavy-Duty Hubs and Spindles
  • Single Point Depth Control
  • Edge Bent Shanks
  • Sapphire Blue Powder Coat Paint
  • tSafety Warning Lights

877-15 Specs & Compare

Product Attributes877-15
Approximate Weight8,920 lbs. (4,046 kg)
Working Width15 ft. 0 in. (4.6 m)
Transport Width16 ft. 6 in. (5.0 m)
Transport HeightN/A
Type of FoldNon-Folding
Number of Shanks20
Shank TypeSpring Clamp, Edge Bent Shank
Shank Size0.5625 in. x 1.75 in. (14.3 x 44.5 mm)
Point Load170 lbs. (77 kg)
Shank Spacing9 in. (229 mm)
Under Frame Clearance25.5 in. (648 mm)
Sweeps10 in. (254 mm)
Number of Blades24
Soil Deflector/Spray ShieldMounted Behind Gangs
Blade Diameter20 in. (508 mm)
Blade Thickness0.197 in. (5.0 mm)
Blade ConcavityLow Concavity
Blade Spacing7.5 in. (191 mm)
Reversible Blade Scrapers4 in. x 0.25 in. (102 x 6.35 mm)
Gang ProtectionC-Cushion
Gang Angle10 Degree
Gang Shaft1.5 in. (38.1 mm)
Gang Bearings1.5 in. (38.1 mm) Flange Type Greaseable
Chopper Reel and 3-Bar Spike DragStandard
Chopper Reel Size16 in. (406 mm) Diameter
Chopper Reel Bars5-Bar, 0.281 x 4 in. (7.1 x 102 mm) Beveled
Chopper Reel BearingsTrunnion Bearings with C-Flex Protection
Chopper Reel AngleMounted at 10 Degree Angle
3-Bar Spike DragAdjustable Down Pressure
3-Bar Spike Drag AngleAdjustable
Spike Size0.75 in. x 11 in. (19.0 x 0279 mm)
Spike SpacingSpaced on 2.5 in. (63.5 mm) Centers
Frame ConstructionLaser Cut/Matchcut Components, Robotically Welded
Walking TandemsStandard in All Locations
Tire Size - Main Frame(4) 280/70R x 15 Radial
Wheel Hubs - Main Frame6-Bolt
Spindles - Main Frame2.25 in. (57.2 mm) Slip-In Spindles
Tire Size - Wing FrameN/A
Wheel Hubs - Wing FrameN/A
Spindles - Wing FrameN/A
Hitch CategoryCat. III Single Lip
Machine Depth ControlSingle Point Depth Control
Safety Warning Lights and SMV EmblemStandard
Safety Chain KitStandard
Powder Coat Paint, Blue SapphireStandard
10 in. Ultra Wing SweepsOptional
Cat. IV Single Lip Hitch ClevisOptional
Cat. V Single Lip Hitch ClevisN/A
Spare Tire and Wheel AssemblyOptional
Horsepower Requirements11 to 12 HP (8 to 9 kW) per Foot
