7812-13 Features & Benefits

Features That Leave the Competition Behind

  • Operating Depth Range of 2” to 5”
  • Individually Mounted 24” Notched or Smooth Blades on 10” Spacing and 17 Degree Angle
  • Rubber Torsion Spring Pressure on Blade Arms
  • Maintenance-Free Dual Tapered Roller Disc Bearings
  • Available with Chevron Reels, Spring Tine Reels, Rubber Rollers or Double Chevron Rollers (Model Dependent)
  • Smoothest Ride of all High Speeds with Spring Cushioned Rollers/Reels; Bounce is Eliminated
  • Tilt Control Feature to Level Front to Rear
  • All Adjustments are Simple; Front Mounted Depth Controls are Easy to Access
  • Laser Cut, Robotically Welded Frame
  • Heavy-Duty Transport Axles with UHMW Maintenance-Free Pivots
  • Heavy-Duty Flotation Tires
  • Walking Tandems on Wings
  • Floating Hitch Helps Maintain an Even Cutting Depth
  • Hydraulic Jack for Easy Hook-ups
  • 13’ Three-Point Hitch Model
  • 17’, 20’ and 23’ Pull-Type Two-Section Folding Models
  • 25’, 30’, 35’ and 40’ Pull-Type Three-Section Folding Models
  • Narrow Transport Width
  • Blue Powder Coat Paint
  • LED Safety Warning Lights

7812-13 Specs & Compare

Model 7812-13
Approximate Weight (with Chevron Reels) 7,948 lbs. (3,605 kg)
Working Width 13 ft. 4 in. (4.1 m)
Transport Width 16 ft. 0 in. (4.9 m)
Transport Height N/A
Operating Depth Range 2 in. to 5 in. (50.8 to 127 mm)
Number of Blades - Front 17
Number of Blades - Rear 16
Blade Diameter 24 in. (610 mm)
Blade Thickness 0.25 in. (6.35 mm)
Blade Concavity 3 in. (76.2 mm)
Blade Spacing - Front and Rear 10 in.
Disc Angle - Front and Rear Pre-Set Non-Adjustable Compound Angle
Number of Disc Bearings - Front 17
Number of Disc Bearings - Rear 16
Disc Protection Torsion Mounted
Disc Bearings Individually Mounted with 5-Lip Seal
Frame Construction Laser Cut/Matchcut Components, Robotically Welded
Transport Axles Three-Point Lift Assist- Optional
Wing Axles N/A
Main Frame Tires N/A
Main Frame Spindles N/A
Main Frame Hubs N/A
Wing Frame Tires N/A
Wing Frame Spindles N/A
Wing Frame Hubs N/A
Hitch Type Three-Point Hitch
Hitch Category Cat. III Quick Hitch Compatible
Machine Depth Control Single Point, Front Mounted Depth Control
Safety Warning Lights and SMV Emblem Standard
Safety Chain Kit Standard
Adjustment Wrenches Standard
Powder Coat Paint, Blue Sapphire Standard
Cat. V Single Lip Hitch with 3 in. Hole N/A
Spare Tire and Wheel for Center Section N/A
Horsepower Requirements 15 to 17 HP (11 to 13 kW) per Foot

Specifications subject to change with or without notice.
